Fig. 215: View Of Fuel Line Bracket Bolt
Courtesy of GENERAL MOTORS CORP.
24. Remove the bolt that secures the fuel line bracket to the left side of the transmission.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Automatic Transmission - 4L60-E/4L65-E/4L70-E - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Fig. 216: View Of Fuel Line Bracket Nut
Courtesy of GENERAL MOTORS CORP.
25. Remove the nut that secures the fuel line bracket to the transmission torque converter
housing.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Automatic Transmission - 4L60-E/4L65-E/4L70-E - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Fig. 217: View Of Transmission Oil Cooler Lines
Courtesy of GENERAL MOTORS CORP.
26. Disconnect the transmission oil cooler lines from the transmission. Refer to Transmission
Fluid Cooler Hose/Pipe Quick-Connect Fitting Disconnection and Connection.
27. Plug the transmission oil cooler line connectors in the transmission case.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Automatic Transmission - 4L60-E/4L65-E/4L70-E - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Fig. 218: Identifying Stud & Bolt Securing Transmission To Engine (Right Side)
Courtesy of GENERAL MOTORS CORP.
28. Remove the stud and the bolt securing the transmission to the engine.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Automatic Transmission - 4L60-E/4L65-E/4L70-E - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
