Chevrolet Silverado / GMC Sierra. Manual - part 1080
Fig. 207: View Of Left Flywheel Inspection Cover
Courtesy of GENERAL MOTORS CORP.
10. Remove the left flywheel inspection cover.
11. Remove the starter motor. Refer to Starter Motor Replacement (4.3L) or Starter Motor
Replacement (4.8L, 5.3L, 6.0L, and 6.2L) or Starter Motor Replacement (6.6L) .
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Automatic Transmission - 4L60-E/4L65-E/4L70-E - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Fig. 208: View Of Right Flywheel Inspection Cover
Courtesy of GENERAL MOTORS CORP.
12. Remove the right flywheel inspection cover.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Automatic Transmission - 4L60-E/4L65-E/4L70-E - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Fig. 209: View Of Flywheel To Torque Converter Bolts
Courtesy of GENERAL MOTORS CORP.
13. Remove the flywheel to torque converter bolts.
14. Lower the transmission to gain access to the top and sides of the transmission.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Automatic Transmission - 4L60-E/4L65-E/4L70-E - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Fig. 210: View Of Transfer Case Vent Tube Hose
Courtesy of GENERAL MOTORS CORP.
15. Disconnect the vent tube hose and the electrical connections from the transfer case, if
equipped.
16. Remove the transfer case, if equipped. Refer to the appropriate procedure:
Transfer Case Assembly Replacement for the MP 1222/1225/1226-NQG transfer
case
Transfer Case Assembly Replacement for the MP 1625/1626-NQF transfer case
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Automatic Transmission - 4L60-E/4L65-E/4L70-E - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
