Chevrolet Silverado / GMC Sierra. Manual - part 1050
Fig. 95: View Of TCC Solenoid & Wiring Harness
Courtesy of GENERAL MOTORS CORP.
5. Disconnect the TCC control solenoid connector.
6. Remove the TCC control solenoid retaining bolts.
7. Remove the TCC control solenoid.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Automatic Transmission - 4L60-E/4L65-E/4L70-E - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Fig. 96: View Of Valve Bore Plug Retainer Ring & Reverse Boost Valve Bushing
Retainer Ring
Courtesy of GENERAL MOTORS CORP.
8. Remove the TCC valve retainer ring (1).
CAUTION: Valve springs can be tightly compressed. Use care when
removing retainers and plugs. Personal injury could
result.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Automatic Transmission - 4L60-E/4L65-E/4L70-E - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Fig. 97: TCC Valve Assembly
Courtesy of GENERAL MOTORS CORP.
9. Remove the following parts:
The valve bore plug
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Automatic Transmission - 4L60-E/4L65-E/4L70-E - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
