Fig. 76: Identifying Improper Engine Oil Cooler Hose/Pipe Retaining Ring 4. Do not install the new retaining ring onto the fitting by pushing the retaining ring.
2008 Chevrolet Silverado 1500 2008 TRANSMISSION Automatic Transmission - 4L60-E/4L65-E/4L70-E - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 77: Ensuring Retaining Ring Is Seated Correctly 5. Ensure that the three retaining ring ears are seen from inside the fitting and that the retaining ring moves freely in the fitting slots.
2008 Chevrolet Silverado 1500 2008 TRANSMISSION Automatic Transmission - 4L60-E/4L65-E/4L70-E - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 78: View Of Cooler Line Quick Connect Fitting 6. Install the cooler line into the quick connect fitting. 7. Insert the cooler line end into the quick connect fitting until a click is either heard or felt.
2008 Chevrolet Silverado 1500 2008 TRANSMISSION Automatic Transmission - 4L60-E/4L65-E/4L70-E - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 79: Do Not Use Plastic Cap On Cooler Line In Order To Install Cooler Line Into 8. Do not use the plastic cap on the cooler line in order to install the cooler line into the fitting. 9. Pull back sharply on the cooler line in order to ensure that the cooler line is fastened into the quick connect fitting.
2008 Chevrolet Silverado 1500 2008 TRANSMISSION Automatic Transmission - 4L60-E/4L65-E/4L70-E - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
