Chery International Maintenance and Service

Maintenance item

Mileage (km)

5000

15000

30000

Spark plug: Check and replace if necessary

★

Air filter: Clean housing & filter element, and replace filter element if necessary

★

Ignition timing: Check

★

Fuel filter: Replace

★

Exhaust system: Check leakage & damage status

★

Rubber ribbed belt: Check tension, and adjust or replace if necessary

★

Transmission: Check leakage or damage

★

Dust cap of constant velocity universal joint: Damage check

★

Steering tie rod end: Check the free play & dust cap

★

Steering universal joint assembly housing:

Dislocation

or damage check

★

Power steering system: Check liquid level and steering gear gap

★

Braking system: visual check for leakage or damage, and check braking fluid level

★

Manual brake: Check its stroke, adjust if necessary

★

Brake friction lining: Check thickness

★

Vehicle bottom protector: Visual check to see if it is damaged

★

Chery International Maintenance and Service

Maintenance item

Mileage (km)

5000

15000

30000

Safety belt: Check to see if it is damaged.

★

Teo-in value, Camber angle: Check, and adjust if necessary

★

Ball stud: Check clearance

★

Rear camshaft rubber hinge: Check to see if it is damaged

★

Engine oil pan bolt: Check to see if it is loose, and then tighten it if necessary

★

Control arm rubber cap: Check to see if it is damaged

★

Braking line: Check to see if it is ageing or damaged

★

Braking hard pipe: Check to prevent from damage, corrosion or joint leakage

★

Joints for fuel system: Check to prevent from ageing, damage or abnormal loose or abrasion

★

Tire (including spare tire): Check the tread pattern depth, then adjust the tire pressure, and
finally check the tire bolt full-load torque

★

Change the position of tires

★

Joint bolt for chassis and vehicle body: Check to see if it is loose, and then tighten it if
necessary

★

Tire: Check to see if it is loose

★

Chery International Maintenance and Service

Maintenance item

Mileage (km)

5000

15000

30000

CO content during idling: Check, and adjust if necessary

★

Trial drive: Check the functions of all systems

★

Notice: For manual transmission, the transmission gear oil shall be replaced every one-year or 30000km mileage. Braking
fluid must be replaced every two-year or 50000km mileage.

First 5000km Free
Maintenance Card

Date: ____

Mileage: _

Purpose: __

License plate number: __

Service Station (seal): __

Signature of owner: ____

CHERY

Service Station

(Seal)

Vehicle data

Owner: _____
Company (name): _
Address: _______________________
Tel: _______________________
E-MAIL: _____________________
Purchase date: _____
Purpose: __________
License plate number: _____

Vehicle chassis Number

Model

Vehicle description

Engine number/ Transmission number

Paint grade/Inner parts

Optional parts
