DESCRIPTION
TORQUE (N·m)
Engine To Transaxle Bolts
80
Exhaust Manifold Nuts
25
Exhaust Manifold Heat Shield Bolts
15
Exhaust Camshaft Timing Belt Pulley Bolt
120
Flywheel Bolts (manual transaxle)
75
Fuel Rail Bracket Bolts
11
Idler Pulley Bolt
40
Intake Camshaft Timing Belt Pulley Bolt
120
Intake Manifold Bolts
10
Intake Manifold Nuts
11
Intake Manifold Bracket Bolts
25
Lower Idler Pulley Bolt
45
Lower Cylinder Block Bolts
23
Oil Filter
25
Oil Pan Bolts
18
Oil Drain Plug
40
Oil Strainer Bolts
18
Oil Pump Bolts
11
(Apply with Loctite 5910 Thread-Locker)
Rear Timing Cover Bolts
7
Timing Belt Upper Cover Bolts
11
Timing Belt Lower Cover Bolts
11
Timing Belt Tensioner Assembly
27
Timing Belt Tensioner Pulley Bolt
30
Throttle Body Bolts
11
Upper Idler Pulley Bolt
45
