Chery SQR 7160 sedan. Manual - part 5

















4 Code

00283，00285，00290，00287 Possible

causes

［Note］Code will be set when sensor has recognizable open or short

problem.

［Method］  Poor sensor connection, coil or wiring harness short, defective

sensor signal circuit in ABS ECU。

●Sensor connector or coil open

●Sensor coil short

●Sensor connector or harness short

to ground or power

●Defective ABS ECU sensor signal

circuit.







Check each wheel sensor

OKAY

Not okay

Check appropriate

sensor connector

Not okay

Okay

Repair connector

Does problem appear again?

No

Go to INTERMITTENT

FAULT DIAGNOSTIC

YES

Check electrical harness between

ABS ECU and sensor

Remove ABS ECU connector.

Check resistance between following

terminals. Is resistance within

1.0~1.3 KOhm?



Wiggling sensor wiring harness and

connector while mearing resistance.

LF: 1-2

RF: 19-20

LR: 5-6

RR: 22-23



Normal

Replace ABS ECU

13









5

Code 01044

Possible causes

［Note］  When ECU software programming code is not consistent with ABS

harness pin, code will be set.

●Pin connection error in ABS harness.

●ABS ECU programming error.





Check if ABS ECU software programming correct

using scan tool.

Correct value:

01901 for SQR 7160 and SQR 7160L

NO

Reprogramme

ABS ECU

YES

Check if ABS harness pin connection

Continuity?

Pin connection: chart 12, 14

NO

Repair harness

14













6

Code 00668

Possible causes

［Note］

When no voltage or high voltage at terminal 30, code is set。

●  Blown ABS system fuse

●  High or low battery voltage

● defective ABS electrical harness

connector

● defective ABS ECU









Check ABS system 30A fuse

Normal

Not normal

Replace fuse

Not normal  Check ABS electrical harness

connector

Not normal

Repair connector

Normal

Retry.Does problem reoccur?

NO

YES

Disconnect ABS electrical harness

and ECU. Turn ignition to ON

position.

Measure voltage between

terminals:

8 and 9: 9.5-16.5V

24 and 25: 9.5-16.5V

8 and 4: 9.5---16.5V

Normal

Replace ABS ECU

Check battery voltage

Go to

INTERMITTENT

FAULT DIAGNOSTIC

15









7

Code 01130

Possible causes

［Note］When ABS is interrupted by high frequency electromagnetic wave

or micro prcrosser recognized an incrorrect input speed signal, code is set.

●  high frequency electromagnetic

wave interference

damaged sensor or sensor harness.

●  defective ABS ECU







No

Not normal

Replace sensor

Check sensor

Normal

Check sensor output voltage

Check wiring harness

between ECU and sensor.

Normal

Replace ABS ECU

16
