Acura MDX (2018 year). Manual - part 19

uu

Audio System Basic Operation

u

Playing a USB Flash Drive

294

Features

1. Select Search.
2. Select a folder.

3. Select a file.

■

How to Select a File from the Music Search List

1

Playing a USB Flash Drive

Use the recommended USB flash drives.

2 General Information on the Audio System

P. 316

Files in WMA/AAC format protected by digital rights
management (DRM) are not played.
The audio system skips to the next file.

If there is a problem, you may see an error message
on the On Demand Multi-Use Display

TM

.

2 iPod/USB Flash Drive P. 310

Folder Selection

File Selection

18 ACURA MDX-31TZ56400.book  294 ページ  ２０１７年８月２３日　水曜日　午後４時１分

295

uu

Audio System Basic Operation

u

Playing a USB Flash Drive

Features

You can select scan, repeat, and random modes when playing a file.

■

Scan

Select SCAN to provide a 10-second sampling
of each file.

■

Random/Repeat

Select repeat or random icon repeatedly until
a desired mode.

■

To turn off a play mode

To turn off scan, select Stop Scan.
To turn off random or repeat, select repeat or random icon repeatedly.

■

How to Select a Play Mode

1

How to Select a Play Mode

Play Mode Menu Items
SCAN
Scan Folders: Provides a 10-second sampling of the
first file in each of the main folders.
Scan Tracks: Provides a 10-second sampling of all
files in the current folder.

Repeat

Random

(repeat off): Repeat mode to off.

(repeat track): Repeats the current file.

(repeat folder): Repeats all files in the current
folder.

(random off): Random mode to off.

(random in folder): Plays all files in the
current folder in random order.

(random all tracks): Plays all files in random
order.

Random Icon

Repeat Icon

18 ACURA MDX-31TZ56400.book  295 ページ  ２０１７年８月２３日　水曜日　午後４時１分

296

uu

Audio System Basic Operation

u

Playing Bluetooth® Audio

Features

Playing Bluetooth® Audio

Your audio system allows you to listen to music from your Bluetooth-compatible
phone.
This function is available when the phone is paired and connected to the vehicle’s
Bluetooth® HandsFreeLink® (HFL) system.

2 Phone Setup P. 401

1

Playing Bluetooth® Audio

Not all Bluetooth-enabled phones with streaming
audio capabilities are compatible with the system.
For a list of compatible phones:

•

U.S.: Visit www.handsfreelink.com/Acura, or call 1-
888-528-7876.

•

Canada: For more information on smartphone
compatibility, call 1-888-528-7876.

In some states, it may be illegal to perform some data
device functions while driving.

If more than one phone is paired to the HFL system,
there will be a delay before the system begins to play.

Some functions may not be available on some
devices.

If a phone is currently connected via Apple CarPlay or
Android Auto, Bluetooth® Audio from that phone is
unavailable. However, a second previously paired
phone can stream Bluetooth® Audio by selecting
Connect to Audio from the Edit Bluetooth
Device.

2 Phone Setup P. 401

Source
Select to change an audio
source.

VOL/

 (Volume/Power)

Knob
Press to turn the audio
system on and off.
Turn to adjust the
volume.

 (Information) Icon

Select to displays the
current file details.
Select

 to displays

the previous screen.

Skip/Seek Icons
Select

 or

 to change files.

On Demand Multi-Use Display

TM

Play Icon

Pause Icon

Browse
Select to displays
the track list
screen.

Audio Menu
Select to display
the menu items.

Folder Up/Down Icons
Select

 or

 to change

folders.

18 ACURA MDX-31TZ56400.book  296 ページ  ２０１７年８月２３日　水曜日　午後４時１分

297

uu

Audio System Basic Operation

u

Playing Bluetooth® Audio

Features

1. Make sure that your phone is paired and

connected to HFL.

2. Select the Bluetooth® Audio mode.

If the phone is not recognized, another HFL-
compatible phone, which is not compatible
for Bluetooth® Audio, may already be
connected.

■

To pause or resume a file

Select the play icon or pause icon.

1. Select Browse.
2. Select a search category (e.g., Albums).
3. Select an item.

u

The selection begins playing.

■

To Play Bluetooth® Audio Files

1

To Play Bluetooth® Audio Files

To play the audio files, you may need to operate your
phone. If so, follow the phone maker’s operating
instructions.

The pause function may not be available on some
phones.

Switching to another mode pauses the music playing
from your phone. This function may not be available
on some phones.

Play Icon

Pause Icon

■

Searching for Music

1

Searching for Music

Depending on the Bluetooth® device you connect,
some or all of the lists may not be displayed.

18 ACURA MDX-31TZ56400.book  297 ページ  ２０１７年８月２３日　水曜日　午後４時１分

298

uu

Audio System Basic Operation

u

Siri Eyes Free

Features

Siri Eyes Free

You can talk to Siri using the Talk button on the steering wheel when your
compatible iPhone is paired to Bluetooth® HandsFreeLink®.

2 Phone Setup P. 401

■

Using Siri Eyes Free

1

Siri Eyes Free

Siri is a trademark of Apple Inc.

Check Apple Inc. website for features available for
Siri.

We recommend against using Siri other than in Siri
Eyes Free while operating a vehicle.

1

Using Siri Eyes Free

Some commands work only on specific phone
features or apps.

 (Hang-up/back) button:

Press to deactivate Siri.

 (Talk) button:

Press and hold until the display changes as shown.

While in Siri Eyes Free:
The display remains the same.
No feedback or commands appear.

Appears when Siri is
activated in Siri Eyes
Free

18 ACURA MDX-31TZ56400.book  298 ページ  ２０１７年８月２３日　水曜日　午後４時１分

299

uu

Audio System Basic Operation

u

Apple CarPlay

Continued

Features

Apple CarPlay

If you connect an Apple CarPlay-compatible iPhone to the system via the 2.5A USB
port (

), you can use the information screen, instead of the iPhone display, to

make a phone call, listen to music, view maps (navigation), and access messages.

2 USB Ports P. 233

*1:The operation methods may differ from your connected iPhone.

■

Apple CarPlay Menu

1

Apple CarPlay

Only iPhone 5 or newer versions with iOS 8.4 or later
are compatible with Apple CarPlay.

Park in a safe place before connecting your iPhone to
Apple CarPlay and when launching any compatible
apps.

To use Apple CarPlay, connect the USB cable to the
2.5A USB port (

).

2 USB Ports P. 233

To directly access the Apple CarPlay phone function,
press the PHONE button. While connected to Apple
CarPlay, calls are only made through Apple CarPlay. If
you want to make a call with Bluetooth®
HandsFreeLink®, turn Apple CarPlay OFF or detach
the USB cable from your iPhone.

2 Setting Up Apple CarPlay P. 301

When your iPhone is connected to Apple CarPlay, it is
not possible to use the Bluetooth® Audio or
Bluetooth® HandsFreeLink®. However, other
previously paired phones can stream audio via
Bluetooth® while Apple CarPlay is connected.

2 Phone Setup P. 401

For details on countries and regions where Apple
CarPlay is available, as well as information pertaining
to function, refer to the Apple homepage.

Go back to the previous
screen of this audio system.

Information Screen

Apple CarPlay menu screen

Go back to the Apple CarPlay menu screen

SMARTPHONE Button
Press to display the Apple CarPlay menu screen.

Interface Dial (ENTER/MENU Button)

*1

Move the interface dial to select the item.
Press

 to enter the item.

BACK Button

*1

Press to go back to the previous display.

18 ACURA MDX-31TZ56400.book  299 ページ  ２０１７年８月２３日　水曜日　午後４時１分

uu

Audio System Basic Operation

u

Apple CarPlay

300

Features

■

Phone

Access the contact list, make phone calls, or listen to voice mail.

■

Messages

Check and reply to text messages, or have messages read to you.

■

Music

Play music stored on your iPhone.

■

Maps

Display Apple Maps and use the navigation function just as you would on your
iPhone.

Only one navigation system (pre-installed navigation or Apple Maps) can give
directions at a time. When you are using one system, directions to any prior
destination set on the other system will be canceled, and the system you are
currently using will direct you to your destination.

1

Apple CarPlay

Apple CarPlay Operating Requirements &
Limitations
Apple CarPlay requires a compatible iPhone with an
active cellular connection and data plan. Your
carrier’s rate plans will apply.

Changes in operating systems, hardware, software,
and other technology integral to providing Apple
CarPlay functionality, as well as new or revised
governmental regulations, may result in a decrease or
cessation of Apple CarPlay functionality and services.
Acura cannot and does not provide any warranty or
guarantee of future Apple CarPlay performance or
functionality.

It is possible to use 3rd party apps if they are
compatible with Apple CarPlay. Refer to the Apple
homepage for information on compatible apps.

Models with navigation system

18 ACURA MDX-31TZ56400.book  300 ページ  ２０１７年８月２３日　水曜日　午後４時１分

Continued

301

uu

Audio System Basic Operation

u

Apple CarPlay

Features

After you have connected your iPhone to the system via the 2.5A USB port (

),

use the following procedure to set up Apple CarPlay. Use of Apple CarPlay will result
in the transmission of certain user and vehicle information (such as vehicle location,
speed, and status) to your iPhone to enhance the Apple CarPlay experience. You will
need to consent to the sharing of this information on the information screen.

■

Enabling Apple CarPlay

Enable Once: Allows only once. (Prompt
shows again next time.)
Always Enable: Allows anytime. (Prompt
does not show again.)
Cancel: Does not allow this consent.

You may change the consent settings under
the Smartphone Settings menu.

■

Setting Up Apple CarPlay

1

Setting Up Apple CarPlay

You can also use the method below to set up Apple
CarPlay:
Press the SETTINGSSelect Smartphone
SettingsApple CarPlay Device List

Use of user and vehicle information
The use and handling of user and vehicle information
transmitted to/from your iPhone by Apple CarPlay is
governed by the Apple iOS terms and conditions and
Apple’s Privacy Policy.

18 ACURA MDX-31TZ56400.book  301 ページ  ２０１７年８月２３日　水曜日　午後４時１分

uu

Audio System Basic Operation

u

Apple CarPlay

302

Features

Press and hold the talk button to activate Siri.

■

Operating Apple CarPlay with Siri

1

Operating Apple CarPlay with Siri

Below are examples of questions and commands for
Siri.

•

What movies are playing today?

•

Call dad at work.

•

What song is this?

•

How’s the weather tomorrow?

•

Read my latest email.

•

Find a table for four tonight in Chicago.

For more information, please visit
www.apple.com/ios/siri.

 (Talk) button:

Press and hold to activate Siri.
Press again to deactivate Siri.

18 ACURA MDX-31TZ56400.book  302 ページ  ２０１７年８月２３日　水曜日　午後４時１分

303

uu

Audio System Basic Operation

u

Android Auto

Continued

Features

Android Auto

When you connect an Android phone to the audio system via the 2.5A USB port
(

), Android Auto is automatically initiated. When connected via Android Auto,

you can use the information screen to access the Phone, Google Maps (Navigation),
Google Play Music, and Google Now functions. When you first use Android Auto, a
tutorial will appear on the screen.
We recommend that you complete this tutorial while safely parked before using
Android Auto.

2 USB Ports P. 233
2 Auto Pairing Connection P. 306

1

Android Auto

To use Android Auto, you need to download the
Android Auto app from Google Play to your
smartphone.

Only Android 5.0 (Lollipop) or later versions are
compatible with Android Auto.
Bluetooth A2DP cannot be used with Android Auto
phone.

Park in a safe place before connecting your Android
phone to Android Auto and when launching any
compatible apps.

To use Android Auto, connect the USB cable to the
2.5A USB port (

).

2 USB Ports P. 233

When your Android phone is connected to Android
Auto, it is not possible to use the Bluetooth® Audio.
However, other previously paired phones can stream
audio via Bluetooth® while Android Auto is
connected.

2 Phone Setup P. 401

18 ACURA MDX-31TZ56400.book  303 ページ  ２０１７年８月２３日　水曜日　午後４時１分

uu

Audio System Basic Operation

u

Android Auto

304

Features

*1:The operation methods may differ from your connected Android phone.

■

Android Auto Menu

1

Android Auto

For details on countries and regions where Android
Auto is available, as well as information pertaining to
function, refer to the Android Auto homepage.

Android Auto Operating Requirements &
Limitations
Android Auto requires a compatible Android phone
with an active cellular connection and data plan.
Your carrier’s rate plans will apply.

Changes in operating systems, hardware, software,
and other technology integral to providing Android
Auto functionality, as well as new or revised
governmental regulations, may result in a decrease or
cessation of Android Auto functionality and services.
Acura cannot and does not provide any warranty or
guarantee of future Android Auto performance or
functionality.

It is possible to use 3rd party apps if they are
compatible with Android Auto. Refer to the Android
Auto homepage for information on compatible apps.

6

Information Screen

Android Auto menu screen

SMARTPHONE Button
Press to display the Android Auto menu screen.

Interface Dial (ENTER/MENU Button)

*1

Move and rotate the interface dial to select the item.
Press

 to enter the item.

BACK Button

*1

Press to go back to the previous display.

18 ACURA MDX-31TZ56400.book  304 ページ  ２０１７年８月２３日　水曜日　午後４時１分

305

uu

Audio System Basic Operation

u

Android Auto

Continued

Features

a

 Maps (Navigation)

Display Google Maps and use the navigation function just as you would with your
Android phone. When the vehicle is in motion, it is not possible to make keyboard
entries. Stop the vehicle in a safe location to undertake a search or provide other
inputs.

Only one navigation system (pre-installed navigation or Android Auto) can give
directions at a time. When you are using one system, directions to any prior
destination set on the other system will be canceled, and the system you are
currently using will direct you to your destination.
The information screen shows you turn-by-turn driving directions to your
destination.

b

 Phone (Communication)

Make and receive phone calls as well as listen to voicemail.

c

 Google Now (Home screen)

Display useful information organized by Android Auto into simple cards that appear
just when they’re needed.

d

 Music and audio

Play Google Play Music and music apps that are compatible with Android Auto.
To switch between music apps, press this icon.

e

 Go back to the previous screen of this audio system.

f

 Voice

Operate Android Auto with your voice.

Models with navigation system

18 ACURA MDX-31TZ56400.book  305 ページ  ２０１７年８月２３日　水曜日　午後４時１分

uu

Audio System Basic Operation

u

Android Auto

306

Features

When you connect an Android phone to the unit via the 2.5A USB port (

),

Android Auto is automatically initiated.

■

Enabling Android Auto

Enable Once: Allows only once. (Prompt
shows again next time.)
Always Enable: Allows anytime. (Prompt
does not show again.)
Cancel: Does not allow this consent.

You may change the consent settings under
the Smartphone Settings menu.

■

Auto Pairing Connection

1

Enabling Android Auto

Only initialize Android Auto when you are safely
parked. When Android Auto first detects your phone,
you will need to set up your phone so that auto
pairing is possible. Refer to the instruction manual
that came with your phone.

You can use the method below to change Android
Auto settings after you have completed the initial
setup:
Press the SETTINGSSelect Smartphone
SettingsAndroid Auto Device List

Use of user and vehicle information
The use and handling of user and vehicle information
transmitted to/from your phone by Android Auto is
governed by Google’s Privacy Policy.

18 ACURA MDX-31TZ56400.book  306 ページ  ２０１７年８月２３日　水曜日　午後４時１分

307

uu

Audio System Basic Operation

u

Android Auto

Features

Press and hold the talk button to operate Android Auto with your voice.

■

Operating Android Auto with Voice Recognition

1

Operating Android Auto with Voice Recognition

Below are examples of commands you can give with
voice recognition:

•

Reply to text.

•

Call my wife.

•

Navigate to Acura.

•

Play my music.

•

Send a text message to my wife.

•

Call flower shop.

For more information, please refer to the Android
Auto homepage.

You can also activate the voice recognition function
by moving

.

 (Talk) button:

Press and hold to operate Android Auto
with your voice.
Press to deactivate voice recognition.

18 ACURA MDX-31TZ56400.book  307 ページ  ２０１７年８月２３日　水曜日　午後４時１分

308

Features

Audio Error Messages

CD Player

If a disc error occurs, you may see the following error messages.

Error Message

Cause

Solution

This function is not available
because the system has
encountered a file error or a
DRM protected file.

Track/file format not supported

●

Current track/file will be skipped. The next supported track/file
plays automatically.

This is a bad disc. Please see
your owner’s manual for
more details. Push Eject.

Mechanical error

●

Press the

 (eject) button and remove the disc, and check that the

error message is cleared.

●

Check that the disc is not damaged or deformed, and insert the
disc again.

2 Protecting CDs P. 317

●

If the error message reappears, press the   button, and pull out
the disc.

●

Insert a different disc.
If the new disc plays, there is a problem with the first disc.

●

If the error message repeats, or the disc cannot be removed,
contact a dealer.
Do not try to force the disc out of the player.

Mecha Error

This is a bad disc. Please see
your owner’s manual for
more details.

Servo error

Check the disc

Disc error

●

Check that the disc is not damaged or deformed.

2 Protecting CDs P. 317

Heat Error

High temperature

●

Turn the audio system off and allow the player to cool down until
the error message is cleared.

18 ACURA MDX-31TZ56400.book  308 ページ  ２０１７年８月２３日　水曜日　午後４時１分

309

uu

Audio Error Messages

u

Hard Disk Drive (HDD) Audio

Features

Hard Disk Drive (HDD) Audio

If an error occurs while playing the Hard Disk Drive (HDD) Audio, you may see the
following error messages. If you cannot clear the error message, contact a dealer.

Error Message

Solution

HDD access error.
Please consult your dealer.

—

The navigation system temperature is too high. For
protection, the system will shut off until it cools down.

Turn the audio system off and allow the player to cool down until
the error message is cleared.

The navigation system atmospheric pressure is too low. For
protection, the system will shut off until the pressure returns
to safe levels.

The navigation system has difficulty reading the HDD when the
atmospheric pressure is too low. The navigation system starts up
automatically when the atmospheric pressure returns to safe
levels.

Unplayable File

Appears when a file format not supported. Current track will be
skipped. The next supported track plays automatically.

There is no data available.

Appears when the HDD is empty or there are no available files in
the HDD.

This function is not available during CD recording while the
CD is recording to the HDD.

Appears when no available function is selected while the CD is
recording to the HDD.

Generating voice recognition commands. Please try again
later.

Appears when no available function is selected while the
dictionary of the Song By Voice

TM

 recognition function is

generated.

Models with navigation system

18 ACURA MDX-31TZ56400.book  309 ページ  ２０１７年８月２３日　水曜日　午後４時１分
