Acura RLX Hybrid (2017 year). Manual - part 10

151

uu

Security System

u

Security System Alarm

Co
ntrols

■

The panic button on the remote
transmitter

If you press the panic button for
approximately one second, the following will
occur for about 30 seconds:
• The horn sounds.
• Some exterior lights flash.

■

Canceling panic mode

Press any button on the remote transmitter, or set the power mode to ON.

■

Panic Mode

Panic
Button

Panic
Button

17 ACURA RLX E-AWD-31TY36300.book  151 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

152

Co
ntrols

Opening and Closing the Windows

Opening/Closing the Power Windows

The power windows can be opened and closed when the power mode is in ON,
using the switches on the doors. The driver’s side switches can be used to open and
close all of the windows.

The power window lock button on the driver’s side must be switched off (not
pushed in, indicator off) to open and close the windows from anywhere other than
the driver’s seat.

When the power window lock button is pushed in, you can only operate the driver’s
window. Turn the power window lock button on when children are in the vehicle.

■

Automatic operation

To open: Push the switch down firmly.
To close: Pull the switch up firmly.

The window opens or closes completely. To
stop the window at any time, push or pull the
switch briefly.

■

Manual operation

To open: Push the switch down lightly, and
hold it until the desired position is reached.
To close: Pull the switch up lightly, and hold it
until the desired position is reached.

■

Opening/Closing the Windows with Auto-Open/Close Function

1

Opening/Closing the Power Windows

The power windows can be operated for up to 10
minutes after you set the power mode to VEHICLE
OFF (LOCK).
Opening either front door cancels this function.

Auto Reverse
If a power window senses resistance when closing
automatically, it stops closing and reverses direction.

The driver’s window auto reverse function is disabled
when you continuously pull up the switch.

The auto reverse function stops sensing when the
window is almost closed to ensure that it fully closes.

3

WARNING

Closing a power window on someone’s
hands or fingers can cause serious injury.

Make sure your passengers are away from
the windows before closing them.

ON
OFF

Power Window
Lock Button

Indicator

Driver’s
Window
Switch

Front Passenger’s
Window Switch

Rear Passenger’s
Window Switches

17 ACURA RLX E-AWD-31TY36300.book  152 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

153

uu

Opening and Closing the Windows

u

Opening/Closing the Power Windows

Co
ntrols

To open: Press the unlock button twice
within 10 seconds and hold it down the
second time. If the windows stop midway,
repeat the procedure.

To open: Unlock the driver’s door with the
key. Within 10 seconds of returning the key to
the central position, turn the key in the unlock
direction and hold it there.
To close: Lock the driver’s door with the key.
Within 10 seconds of returning the key to the
central position, turn the key in the lock
direction and hold it there.

Release the key to stop the windows/
moonroof at the desired position. If you want
further adjustment, repeat the same
operation.

■

Opening the Windows and Moonroof with the Remote

Unlock
Button

■

Opening/Closing the Windows and Moonroof with the Key

Close

Open

17 ACURA RLX E-AWD-31TY36300.book  153 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

154

Co
ntrols

Opening and Closing the Moonroof

You can only operate the moonroof when the power mode is in ON. Use the switch
in the front of the ceiling to open and close the moonroof.

■

Automatic operation

To open: Pull the switch back firmly.
To close: Push the switch forward firmly.

The moonroof will automatically open or close
all the way. To stop the moonroof midway,
touch the switch briefly.

■

Manual operation

To open: Pull the switch back lightly, and
hold it until the desired position is reached.
To close: Push the switch forward lightly, and
hold it until the desired position is reached.

■

Tilting the moonroof up

To tilt: Push on the center of the moonroof
switch.
To close: Push the switch forward firmly, then
release.

■

Opening/Closing the Moonroof

1

Opening/Closing the Moonroof

NOTICE

Opening the moonroof in below freezing
temperature or when it is covered with snow or ice
can damage the moonroof panel or motor.

The power moonroof can be operated for up to 10
minutes after you set the power mode to VEHICLE
OFF (LOCK).
Opening either front door cancels this function.

When resistance is detected, the auto reverse
function causes the moonroof to change directions,
then stop. Auto reverse stops sensing when the
moonroof is almost closed to ensure that it fully
closes.

3

WARNING

Opening or closing the moonroof on
someone’s hands or fingers can cause
serious injury.

Make sure all hands and fingers are clear of
the moonroof before opening or closing it.

Close

Open

Tilt

17 ACURA RLX E-AWD-31TY36300.book  154 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

155

Continued

Co
ntrols

Operating the Switches Around the Steering Wheel

POWER Button

■

Changing the Power Mode

1

POWER Button

POWER Button Operating Range

You can start the power system when the keyless
access remote is inside the vehicle.
The power system may also start if the keyless access
remote is close to the door or window, even if it is
outside the vehicle.

ON mode:
Indicator in the button is off, if the engine is running.

If the keyless access remote battery is weak, beeper
sounds and the To Start, Hold Remote Near Start
Button message appears on the multi-information
display.

2 If the Keyless Access Remote Battery is

Weak P. 530

Do not leave the power mode in ACCESSORY or ON
when you get out.

Operating Range

VEHICLE OFF (LOCK)
Indicator in the button is off.
The power to all electrical components is turned
off.

Press the button.

Without pressing
the brake pedal

ACCESSORY
Indicator in the button is on.
Operate the audio system and other accessories
in this position.

ON
Indicator in the button is on.
All electrical components can be used.

Indicator

17 ACURA RLX E-AWD-31TY36300.book  155 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

156

uu

Operating the Switches Around the Steering Wheel

u

POWER Button

Co
ntrols

If you leave the vehicle for 30 to 60 minutes with the transmission in

(

P and the

power mode in ACCESSORY, the vehicle automatically goes into the mode similar to
VEHICLE OFF (LOCK) to avoid the 12-volt battery drain.

When in this mode, you cannot lock or unlock doors with the remote transmitter or
the keyless access system.

Press the POWER button to switch the mode to VEHICLE OFF (LOCK).

If you open the driver’s door when the power mode is set to ACCESSORY, a warning
buzzer sounds.

■

Automatic Power Off

■

Power Mode Reminder

17 ACURA RLX E-AWD-31TY36300.book  156 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

157

uu

Operating the Switches Around the Steering Wheel

u

POWER Button

Co
ntrols

Warning buzzers may sound from inside or/
and outside the vehicle to remind you that the
keyless access remote is out of the vehicle. If
the buzzer continues even after the remote is
put back inside, place it to be within its
operational range.

■

When the power mode is in ON

If the keyless access remote is taken out of the
vehicle, and the driver’s door is closed,
warning buzzers sound from both inside and
outside the vehicle. A warning message on
the multi-information display notifies the
driver inside that the remote is out.

■

When the power mode is in
ACCESSORY

If the keyless access remote is taken out of the
vehicle, and the driver’s door is closed, a
warning buzzer sounds from outside the
vehicle.

■

Keyless Access Remote Reminder

1

Keyless Access Remote Reminder

When the keyless access remote is within the
system’s operational range, and the driver’s door is
closed, the warning function cancels.

If the keyless access remote is taken out of the vehicle
after the power system has been turned on, you can
no longer change the POWER button mode or
restart the power system. Always make sure if the
remote is in your vehicle when you operate the
POWER button.

Removing the keyless access remote from the vehicle
through a window does not activate the warning
buzzer.

Do not put the keyless access remote on the
dashboard or in the glove box. It may cause the
warning buzzer to go off. Under some other
conditions that can prevent the vehicle from locating
the remote, the warning buzzer may also go off even
if the remote is within the system’s operational
range.

17 ACURA RLX E-AWD-31TY36300.book  157 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

158

uu

Operating the Switches Around the Steering Wheel

u

Turn Signals

Co
ntrols

Turn Signals

The turn signals can be used when the power
mode is in ON.

■

One-touch turn signal

When you lightly push up or down and release
the turn signal lever, the exterior turn signals
and turn signal indicator blink three times.

This feature can be used when signaling for a
lane change.

Right Turn

Left Turn

17 ACURA RLX E-AWD-31TY36300.book  158 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

159

uu

Operating the Switches Around the Steering Wheel

u

Light Switches

Continued

Co
ntrols

Light Switches

Rotating the light switch turns the lights on
and off, regardless of the power mode
setting.

■

High beams

Push the lever forward until you hear a click.

■

Low beams

When in high beams, pull the lever back to
return to low beams.

■

Flashing the high beams

Pull the lever back, and release it.

■

Lights off

Turn the lever to OFF either when:
• The transmission is in

(

P.

• The parking brake is applied.

To turn the lights on again, turn the lever to
OFF to cancel the lights off mode. Even if you
do not cancel the lights off mode, the lights
come on automatically when:
• The gear position is changed out of

(

P.

• The parking brake is released.
• The vehicle starts to move.

■

Manual Operation

1

Light Switches

If you leave the power mode in VEHICLE OFF (LOCK)
with the lights on, a light on reminder chime will
sound when you open the driver’s door.

When the lights are on, the lights on indicator in the
instrument panel will be on.

2 Lights On Indicator P. 85

If you sense that the level of the headlights is
abnormal, have your vehicle inspected by a dealer.

Do not leave the lights on when the power system is
off because it will cause the 12-volt battery to
discharge.

Your vehicle is equipped with the automatic
headlight adjusting system that automatically adjusts
the vertical angle of the headlights. If you find a
significant change in the vertical angle of the
headlights, there may be a problem with the system.
Have your vehicle checked by a dealer.

High Beams

Flashing the high beams

Low Beams

Turns on parking, side marker,
tail, and rear license plate lights

Turns on headlights, parking, side
marker, tail, and rear license plate
lights

17 ACURA RLX E-AWD-31TY36300.book  159 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

uu

Operating the Switches Around the Steering Wheel

u

Light Switches

160

Co
ntrols

Automatic lighting control can be used when
the power mode is in ON.

When the light switch is in AUTO, the
headlights and other exterior lights will switch
on and off automatically depending on the
ambient brightness.

You can change the auto light sensitivity
setting.

2 Customized Features P. 113, 283

■

Automatic Lighting Control

1

Automatic Lighting Control

We recommend that you turn on the lights manually
when driving at night, in a dense fog, or in dark areas
such as long tunnels or parking facilities.

The light sensor is in the location shown below.
Do not cover this light sensor with anything;
otherwise, the automatic lighting system may not
work properly.

Adjust the auto light sensitivity as follows:

2 Customized Features P. 113, 283

Setting

The exterior lights come on

when the ambient light is at

MAX

HIGH

MID

LOW

MIN

Light Sensor

Bright

Dark

17 ACURA RLX E-AWD-31TY36300.book  160 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

161

uu

Operating the Switches Around the Steering Wheel

u

Light Switches

Co
ntrols

The headlights automatically come on when the wipers are used several times within
a certain intervals with the headlight switch in AUTO.
The headlights automatically go off a few minutes later if the wipers are stopped.

The headlights, all other exterior lights, and the instrument panel lights turn off 15
seconds after you set the power mode to VEHICLE OFF (LOCK), take the remote with
you, and close the driver's door.

If you set the power mode to VEHICLE OFF (LOCK) with the headlight switch on, but
do not open the door, the lights turn off after 10 minutes (three minutes, if the
switch is in the AUTO position).

The lights turn on again when you unlock or open the driver’s door. If you unlock
the door, but do not open it within 15 seconds, the lights go off. If you open the
driver’s door, you will hear a lights on reminder chime.

■

Headlight Integration with Wipers

*

■

Automatic Lighting Off Feature

1

Headlight Integration with Wipers

*

This feature activates when the headlights are off in
AUTO.
The instrument panel brightness does not change
when the headlights come on.

At dark ambient light levels, the automatic lighting
control feature turns on the headlights, regardless of
the number of wiper sweeps.

1

Automatic Lighting Off Feature

 You can change the headlight auto off timer setting.

2 Customized Features P. 113, 283

* Not available on all models

17 ACURA RLX E-AWD-31TY36300.book  161 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

162

uu

Operating the Switches Around the Steering Wheel

u

Fog Lights

Co
ntrols

Fog Lights

When the low beam headlights are on, turn
the fog light switch on to use the fog lights.

Daytime Running Lights

The low beam headlights come on slightly dimmer than normal when the following
conditions have been met:
• The power mode is in ON.
• The headlight switch is AUTO, or in

.

• The parking brake is released.

The low beam headlights return to the original brightness once the headlight switch
is turned on, or when the headlight switch is in AUTO and it is getting darker
outside.

1

Fog Lights

The fog lights go off when the headlights turn off, or
when the daytime running lights are on.

Fog Light Switch

1

Daytime Running Lights

The daytime running lights come on dimmer when
the headlight switch is in

 than when it is in

AUTO. In AUTO, if the ambient brightness is dark,
the low beam headlights come on.

U.S. models

17 ACURA RLX E-AWD-31TY36300.book  162 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

163

uu

Operating the Switches Around the Steering Wheel

u

Wipers and Washers

Continued

Co
ntrols

Wipers and Washers

The windshield wipers and washers can be
used when the power mode is in ON.

■

MIST

The wipers run at high speed until you release
the lever.

■

Wiper switch (OFF, LO, HI)

Change the wiper switch setting according to
the amount of rain.

■

AUTO

2 Automatic Intermittent Wipers P. 164

■

Washer

Sprays while you pull the lever toward you.
When you release the lever, the wipers make
two or three more sweeps before stopping.

1

Wipers and Washers

NOTICE

Do not use the wipers when the windshield is dry.
The windshield will get scratched, or the rubber
blades will get damaged.

NOTICE

In cold weather, the blades may freeze to the
windshield, becoming stuck.
Operating the wipers in this condition may damage
them. Use the defroster to warm the windshield,
then turn the wipers on.

If the vehicle speeds up while the wipers are
operating intermittently, the length of the wipe
interval shortens.
When the vehicle starts moving, the wipers make a
single sweep.

Turn the washers off if no washer fluid comes out.
The pump may get damaged.

The wiper motor may stop motor operation
temporarily to prevent an overload. Wiper operation
will return to normal within a few minutes, once the
circuit has returned to normal.

MIST

OFF

LO: Low speed wipe

HI: High speed wipe

Pull to
use
washer.

AUTO: Wiper speed varies
automatically

17 ACURA RLX E-AWD-31TY36300.book  163 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

uu

Operating the Switches Around the Steering Wheel

u

Wipers and Washers

164

Co
ntrols

When you push the lever down to AUTO, the
windshield wipers sweep once, and go into
the automatic mode.

The wipers operate intermittently, at low
speed, or at high speed and stops in
accordance with the amount of rainfall the
rainfall sensor detects.

■

AUTO sensitivity adjustment

When in AUTO, you can also adjust the
rainfall sensor sensitivity using the adjustment
ring.

Sensor sensitivity

■

Automatic Intermittent Wipers

1

Wipers and Washers

If the wipers stop operating due to any obstacle such
as the build-up of snow, park the vehicle in a safe
place.
Rotate the wiper switch to OFF, and set the power
mode to ACCESSORY or VEHICLE OFF (LOCK), then
remove the obstacle.

1

Automatic Intermittent Wipers

The rainfall sensor is in the location shown below.

Do not put the wiper lever in AUTO when cleaning
the windshield or driving through a car wash. If the
wiper lever is in AUTO, and the power mode is in ON,
the rainfall sensor may respond to your hand or car
wash liquids, and the wipers may operate
automatically.

Rainfall Sensor

Adjustment Ring

Low sensitivity:
Lower speed, fewer sweeps

High sensitivity:
Higher speed, more sweeps

17 ACURA RLX E-AWD-31TY36300.book  164 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

165

uu

Operating the Switches Around the Steering Wheel

u

Wipers and Washers

Co
ntrols

Turn the headlights on and press the
headlight washer button to operate.
The headlight washers also operate when you
turn the windshield washers for the first time
after the power mode sets to ON.

■

Headlight Washers

Canadian models

1

Headlight Washers

The headlight washers use the same fluid reservoir as
the windshield washers.

Headlight
Washer
Button

17 ACURA RLX E-AWD-31TY36300.book  165 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

166

uu

Operating the Switches Around the Steering Wheel

u

Brightness Control

Co
ntrols

Brightness Control

When the power mode is in ON, you can use
the

(

+ or

(

- button to adjust instrument

panel brightness.
To brighten: Press the

(

+ button.

To dim: Press the

(

- button.

You will hear a beep when the brightness
reaches minimum or maximum. The multi-
information display will return to its original
state several seconds after you adjust the
brightness.

■

Brightness level indicator

The brightness level is shown on the multi-
information display while you are adjusting it.

■

Adjusting the Instrument Panel Brightness

1

Adjusting the Instrument Panel Brightness

Instrument panel brightness varies, depending on
whether the exterior lights are on or off. The
instrument panel dims to reduce glare when they are
on.

When it is bright outside and the headlight
integration with the wiper

*

 is activated, the

instrument panel brightness does not change.

Pushing or rolling the right selector wheel changes to
a different display.

If you press the

(

+ button until the brightness display

is up to max, the beeper sounds. This cancels the
reduced instrument panel brightness when the
parking lights are on.

The brightness can be set differently for when the
exterior lights are on, and when they are off.

(

+ Button

(

- Button

* Not available on all models

17 ACURA RLX E-AWD-31TY36300.book  166 ページ  ２０１６年６月１７日　金曜日　午前８時２９分
