*02
HFL Buttons
Hard Reset
Linking
Pairing
Soft Reset (cellular phone)
Software Version
Standard Ringtone
23-369
A
B
• HFL TALK button (A): Use this button on the steering
wheel to give commands. Press the button before a
voice command is given.
• HFL BACK button (B): Use this button on the steering
wheel to end a call or return to a previous prompt in
the HFL menu. Pressing the button twice or holding it
down returns you to the HFL main menu.
Hard resets clear the saved settings in the cell phone
and restores it to the factory defaults. A hard reset
should be done only as a last resort (see the sell phone
owner’s manual for more information).
This is when your paired phone is actively ready to use
the HFL system. You can pair up to six phones to the
HFL system, but only one phone can be linked at a time.
If two paired phones are in the vehicle, only the phone
that is linked can use the HFL system and functions. The
second phone must be used as a normal handset.
A description for linking two Bluetooth devices together.
In this case, you are linking a cell phone with the HFL
system. After the pairing process is complete, the
devices are able to recognize each other and
communicate wirelessly via Bluetooth.
This helps to restore the basic functions of the phone.
To do a soft reset, turn the phone power off, remove
and reinsert the cell phone battery, then turn the phone
back on.
This refers to the software version loaded in the cell
phone. The software version that was tested and
determined to be compatible with the HFL system may
be listed on the HFL website. Not all software versions
are compatible with the HFL system.
These ringtones come factory-installed on the cell
phone.
08/08/21 14:18:38 61SNR030_230_0372
