05 06 07 SNR9A00J54400020371KBAT50 20-23 Rear Door Glass and Regulator Replacement A B C F G H E C E D Fastener Locations : Bolt, 2 6 x 1.0 mm A B A C Fastener Locations : Bolt, 1 A : Screw, 1 D 4 x 0.7 mm 6 x 1.0 mm A B C D NOTE: Put on gloves to protect your hands. 1. Remove the door panel (see page 20-17). 2. Detach the harness clip (A), and disconnect the power door lock actuator connector (B). Remove 3. Pass the cable (D) and the harnesses (E) through the holes (F) and slit (G) in the plastic cover (H), 4. Carefully move the glass (A) until you can see the bolts, then remove them. Release the glass from 5. Remove the bolt (A) from the rear lower channel (B). Pull the glass run channel (C) away as needed, and 08/08/21 14:59:08 61SNR030_200_0025 |
