Fig. 2: Identifying FAM (Front Area Module) Components (1 Of 2)
Courtesy of KIA MOTORS AMERICA, INC.



2008 Kia Sedona

2008 ELECTRICAL Fuses & Relays - Sedona



Microsoft



Saturday, May 22, 2010 4:05:37 PM

Page 2

© 2006 Mitchell Repair Information Company, LLC.

Fig. 3: Identifying FAM (Front Area Module) Components (2 Of 2)
Courtesy of KIA MOTORS AMERICA, INC.

INSPECTION

FUSE

1. Be sure there is no play in the fuse holders, and that the fuses are held securely.

2. Are the fuse capacities for each circuit correct?

3. Are there any blown fuses?

If a fuse is to be replaced, be sure to use a new fuse of the same capacity. Always determine why the fuse
blew first and completely eliminate the problem before installing a new fuse.

RELAY

1. Be sure that the relays are held the each module securely.



2008 Kia Sedona

2008 ELECTRICAL Fuses & Relays - Sedona



Microsoft



Saturday, May 22, 2010 4:05:37 PM

Page 3

© 2006 Mitchell Repair Information Company, LLC.

2. Are the relay types for each circuit correct?

Fig. 4: Identifying Relays (1 of 2)
Courtesy of KIA MOTORS AMERICA, INC.

Fig. 5: Identifying Relays (2 Of 2)
Courtesy of KIA MOTORS AMERICA, INC.



2008 Kia Sedona

2008 ELECTRICAL Fuses & Relays - Sedona



Microsoft



Saturday, May 22, 2010 4:05:37 PM

Page 4

© 2006 Mitchell Repair Information Company, LLC.

Fig. 6: Identifying Relay Terminals (Types A & B)
Courtesy of KIA MOTORS AMERICA, INC.

Fig. 7: Identifying Relay Terminals (Types C & D)
Courtesy of KIA MOTORS AMERICA, INC.
