YES

Go to TERMINAL AND CONNECTOR INSPECTION.

NO

Fault is intermittent caused by poor contact in the sensor's and/or ECM's connector or was repaired and
ECM memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending,
corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to
"VERIFICATION OF VEHICLE REPAIR" procedure.

TERMINAL AND CONNECTOR INSPECTION

Refer to DTC B2119.

POWER SUPPLY CIRCUIT INSPECTION

1. Check open in ground circuit

1. Ignition "ON" & engine "OFF".

2. Measure the resistance between Right turn signal lamp power circuit of FAM (BCM-FE-39) and

turn lamp (E25-1).

Specification: 0 ohms

Fig. 219: Measuring Resistance Between Right Turn Signal Lamp Power Circuit Of FAM
(BCM-FE-39) And Turn Lamp (E25-1)
Courtesy of KIA MOTORS AMERICA, INC.

3. Is the measured resistance within the specification?



2008 Kia Sedona EX

2008 ACCESSORIES & BODY, CAB BCM (Body Control Module) - Sedona



Microsoft



Monday, May 24, 2010 4:19:20 PM

Page 261

© 2006 Mitchell Repair Information Company, LLC.

YES

Go to "GROUND CIRCUIT INSPECTION".

NO

Repair open to ground in power circuit and go to "VERIFICATION OF VEHICLE REPAIR".

GROUND CIRCUIT INSPECTION

1. Check open in ground circuit.

1. Ignition "ON" & engine "OFF".

2. Measure the resistance between Right turn signal lamp ground circuit (E25-3) and chassis ground.

Specification: 0 ohms

Fig. 220: Measuring Resistance Between Right Turn Signal Lamp Ground Circuit (E25-3)
And Chassis Ground
Courtesy of KIA MOTORS AMERICA, INC.

3. Is the measured resistance within the specification?

YES

Go to "COMPONENT INSPECTION".

NO

Repair open to ground in power circuit and go to "VERIFICATION OF VEHICLE REPAIR".

COMPONENT INSPECTION

Refer to DTC B2535.

VERIFICATION OF VEHICLE REPAIR



2008 Kia Sedona EX

2008 ACCESSORIES & BODY, CAB BCM (Body Control Module) - Sedona



Microsoft



Monday, May 24, 2010 4:19:20 PM

Page 262

© 2006 Mitchell Repair Information Company, LLC.

Refer to DTC B2119.

DTC B2539 LEFT TURN SIGNAL LAMP CIRCUIT SHORT TO GROUND ERROR

COMPONENT LOCATION

Fig. 221: Identifying Headlamp, Fog Lamp & Turn Signal Connectors
Courtesy of KIA MOTORS AMERICA, INC.

GENERAL DESCRIPTION

Refer to DTC B2535.

DTC DESCRIPTION

The ECM sets DTC B2537 if short to ground in Right turn signal lamp circuit is detected.

DTC DETECTING CONDITION

Refer to DTC B2543.

MONITOR DTC STATUS

1. Connect scan tool to Data Link Connector (DLC).

2. Ignition "ON" & engine "OFF" & FAM: "ON".

3. Select "Diagnostic Trouble Codes (DTCs)"mode and monitor "DTC Status" parameter.



2008 Kia Sedona EX

2008 ACCESSORIES & BODY, CAB BCM (Body Control Module) - Sedona



Microsoft



Monday, May 24, 2010 4:19:20 PM

Page 263

© 2006 Mitchell Repair Information Company, LLC.

Fig. 222: Identifying Scan Tool Display - Diagnostic Trouble Codes (DTCs)
Courtesy of KIA MOTORS AMERICA, INC.

4. Is the DTC B2539 present?

YES

Go to TERMINAL AND CONNECTOR INSPECTION.

NO

Fault is intermittent caused by poor contact in the sensor's and/or ECM's connector or was repaired and
ECM memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending,
corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to
"VERIFICATION OF VEHICLE REPAIR" procedure.

TERMINAL AND CONNECTOR INSPECTION

Refer to DTC B2119.

POWER SUPPLY CIRCUIT INSPECTION

1. Check short in power circuit

1. Ignition "ON" & engine "OFF".

2. Disconnect Left turn signal lamp.

3. Measure the resistance between Left turn signal lamp power circuit of FAM (BCM-FE-52).

Specification: infinity ohms
