Model MA TOW Tractor. Manual - part 58
Chapter 4: Illustrated Parts List
Jan. 1997
Section 4-2
p. 117
32a-1
388 40-2092908
----------------
fan
1
As Req'd
32a-2
388 1000-26085
----------------
hex head bolt
4
"
32a-3
388 40-0039306
----------------
flat washer
4
"
32A-4
388 40-0000218
----------------
FAN SPACER
1
"
32A-5
388 40-3082601
----------------
WATER PUMP PULLEY
1
"
32A-6
388 40-3035067
----------------
WATER PUMP
1
"
32A-
388 255360
----------------
GASKET, WATER PUMP
1
"
32A-7
388 40-0038442
----------------
HEX HEAD BOLT
3
"
32A-8
388 40-0039302
----------------
LOCK WASHER
3
"
32A-9
----- ----------------
T6-7200-075
FAN BELT
1
"
32A-10 388 40-0004628
----------------
BELT, VACUUM PUMP
1
"
32A-11 ----- ----------------
#28
HOSE CLAMP
6
"
32A-12 388 4452-00
----------------
HOSE, CONNECTOR
1
"
32A-13 388 40-3070702
----------------
PIPE
1
"
32A-14 ----- ----------------
T6-7200-110
RADIATOR HOSE, LOWER
1
"
32A-15 388 40-3070801
----------------
THERMOSTAT HOUSING
1
"
32A-
388 205445-00
----------------
THERMOSTAT
1
"
32A-
388 266701-00
----------------
GASKET, THERMOSTAT HOUSING
1
"
32A-16 ----- ----------------
T6-7200-115
RADIATOR HOSE, UPPER
1
"
32A-17 ----- ----------------
3/8-16NCX3"
HEX HEAD BOLT
4
"
32A-18 ----- ----------------
3/8
LOCK WASHER
4
"
32a-
371 0202400
T6-1001-201
water temperature sensing unit
1
As Req'd
32a-
371 104680
T6-7010-153
water temperature gauge
1
"
32a-
102 020-020
----------------
water temperature switch, 210°
1
"
32a-
102 020-004
----------------
low coolant switch
1
"
Fig &
Co Vendor Part
Tug Part Number
Description
Qty
Effective
Ind#
de Number
