117

MAINTENANCE

Lights

Brake Lights

When the brake pedal is depressed, the brake light comes on. Check the
brake light before each ride.

1. Turn the ignition switch to the LIGHTS ON position.

2. Apply the brakes. The brake light should come on after about 10

mm (0.4 in.) of pedal travel. If the light doesn't come on, check the
bulb.

Vehicle Immersion

NOTICE: If your vehicle becomes immersed, major engine damage can result

if the machine is not thoroughly inspected. Take the vehicle in for
service before starting the engine. Your POLARIS dealer can provide
this service.

If it's impossible to take your vehicle to a dealer before starting it,
follow the steps outlined below.

1. Move the vehicle to dry land.

2. Check the air box. If water is present, dry the air box and replace the

filter with a new filter. Thoroughly dry the air pre-filter. See pages
106-107.

3. Remove the spark plug.

4. Turn the engine over several times.

5. Dry the spark plug and reinstall it, or install a new plug.

6. Attempt to start the engine. If necessary, repeat the drying

procedure.

7. Take the vehicle in for service as soon as possible, whether you

succeed in starting it or not. Your POLARIS dealer can provide the
required service.

8. If water has been ingested into the PVT follow the procedure on

page 105 for drying.

118

MAINTENANCE

Battery

Battery electrolyte is poisonous. It contains sulfuric acid. Serious burns can
result from contact with skin, eyes or clothing.
Antidote:
External: Flush with water.
Internal: Drink large quantities of water or milk. Follow with milk of magnesia,
beaten egg, or vegetable oil. Call physician immediately.
Eyes: Flush with water for 15 minutes and get prompt medical attention.
Batteries produce explosive gases. Keep sparks, flame, cigarettes, etc. away.
Ventilate when charging or using in an enclosed space. Always shield eyes
when working near batteries. KEEP OUT OF REACH OF CHILDREN.

Your vehicle may have either a sealed battery, which requires little
maintenance, or a conventional battery. A sealed battery can be
identified by its flat covers on the top of the battery. A conventional
battery has six filler caps on the top of the battery.

Always keep battery terminals and connections free of corrosion. If
cleaning is necessary, remove the corrosion with a stiff wire brush.
Wash with a solution of one tablespoon baking soda and one cup water.
Rinse well with tap water and dry off with clean shop towels. Coat the
terminals with dielectric grease or petroleum jelly. Be careful not to
allow cleaning solution or tap water into a conventional battery.

WARNING

119

MAINTENANCE

Battery

Improperly connecting or disconnecting battery cables can result in an explosion
and cause serious injury or death. When removing the battery, always
disconnect the negative (black) cable first. When reinstalling the battery, always
connect the negative (black) cable last.

Battery Removal

1. Remove the driver’s seat. See

page 28.

2. On conventional batteries,

remove the battery vent tube.

3. Disconnect the black (negative)

battery cable first.

4. Disconnect the red (positive)

battery cable last.

5. Lift the battery out of the vehicle. Be careful not to tip a

conventional battery sideways, which could spill electrolyte.

NOTICE: If electrolyte spills, immediately wash it off with a solution of one

tablespoon baking soda and one cup water to prevent damage to the
vehicle.

WARNING

120

MAINTENANCE

Battery

Battery Installation

Using a new battery that has not been fully charged can damage the
battery and result in a shorter life. It can also hinder vehicle
performance. Follow the battery charging instructions on page 122
before installing the battery.

An optional extreme use battery may be available for your model. If the
performance of the factory-installed battery is inadequate due to
operation in extreme cold or due to extended use of multiple electrical
accessories, please see your POLARIS dealer or other qualified
personnel. Ask your dealer to provide any installation procedures that
may differ for an extreme use battery.

1. Ensure that the battery is fully charged.

2. Place the battery in the battery holder.

3. On conventional batteries, install the battery vent tube (sealed

batteries do not have a vent tube). The vent tube must be free of
obstructions and securely installed. Route the tube away from the
frame and vehicle body to prevent contact with electrolyte.

WARNING! Battery gases could accumulate in an improperly installed vent tube
and cause an explosion, resulting in serious injury or death. Always ensure that
the vent tube is free of obstructions and is securely installed as recommended.

4. Coat the terminals with dielectric grease or petroleum jelly.

5. Connect and tighten the red (positive) cable first.

6. Connect and tighten the black (negative) cable last.

7. Verify that cables are properly routed.

8. Reinstall the driver’s seat.
