109

MAINTENANCE

Brakes

The front and rear brakes are hydraulic disc type brakes activated by the
brake pedal. See page 36.

Always check brake pedal travel and the brake fluid reservoir level
before each use of the vehicle. When applied, the brake pedal should
feel firm. Any sponginess would indicate a possible fluid leak or low
brake fluid level, which must be corrected before riding. See page 110
for brake fluid information.

If you discover any irregularities in brake system operation, including
excessive pedal travel, contact your POLARIS dealer or other qualified
personnel for proper diagnosis and repairs.

WARNING! Operating the vehicle with a spongy brake pedal can result in loss
of braking, which could cause an accident resulting in severe injury or death.
Never operate the vehicle with a spongy-feeling brake pedal.

110

MAINTENANCE

Brakes

Brake Fluid

Inspect the level of the brake fluid before each operation. If the fluid
level is low add DOT 4 brake fluid only. See page 132 for the part
numbers of POLARIS products.

WARNING! After opening a bottle of brake fluid, always discard any unused
portion. Never store or use a partial bottle. Brake fluid is hygroscopic, meaning it
rapidly absorbs moisture from the air. The moisture causes the boiling
temperature of the brake fluid to drop, which can lead to early brake fade and
the possibility of accident or severe injury.

Change the brake fluid every two
years and any time the fluid
becomes contaminated, the fluid
level is below the minimum, or if
the type and brand of the fluid in
the reservoir are unknown.
Access the brake fluid reservoir
through the left front wheel well.

1. Position the vehicle on a

level surface.

2. Place the transmission in

PARK.

3. View the brake fluid level in

the reservoir. The level
should be between the
maximum and minimum
level lines.

4. If the fluid level is lower

than the lower level line, add
brake fluid to the upper line.

5. Apply the brake forcefully for a few seconds and check for fluid

leakage around the fittings.

Brake Fluid

Reservoir

Maximum

Minimum

111

MAINTENANCE

Brakes

Brake Inspection

1. Check the brake system for

fluid leaks.

2. Check the brake pedal for

excessive travel or a spongy
feel.

3. Check the friction pads for

wear, damage and looseness.

4. Check brake discs for signs

of cracks, excessive
corrosion, warping or other
damage. Clean any grease
using an approved brake
cleaner or alcohol.

WARNING! Do not apply WD-40 or any petroleum product to brake discs.
These types of products are flammable and may also reduce the friction
between the brake pad and caliper.

5. Inspect the brake disc spline and pad wear surface for excessive

wear. Change pads when worn to 0.030" (0.762 mm).

Steering Wheel Inspection

Check the steering wheel for specified freeplay and smooth operation at
the intervals outlined in the Periodic Maintenance Chart beginning on
page 83.

1. Position the vehicle on level ground.

2. Lightly turn the steering wheel left and right.

3. There should be 0.8"-1.0" (20-25 mm) of freeplay.

4. If there is excessive freeplay or strange noises, or the steering feels

rough or “catchy,” have the steering system inspected by an
authorized POLARIS dealer or other qualified personnel.

0.030" (0.762mm)

112

MAINTENANCE

Suspension Settings

The front and rear suspensions are preload adjustable, with five settings
on each axle.

The suspensions are set on the lowest (softest) setting at the factory.
This setting is appropriate for nearly all riding conditions. Since the
vehicle is equipped with full skid plates, suspension adjustment is not
necessary.

If desired, the suspension may be adjusted to maintain vehicle clearance
height when carrying loads. Your POLARIS dealer can provide the tool
required to make suspension adjustments. Elevate the vehicle slightly
for easier adjustment.

Always heed the following rules if you make adjustments to this
suspension.
• Always return the suspension to the lowest (softest) setting after the

load is removed from the vehicle. The increased suspension height
will negatively impact vehicle stability when operating without a
load.

• Always apply the same adjustment setting to all four wheels.
• Never operate the vehicle on the highest (stiffest) or second highest

preload settings without a total combined payload in the vehicle of
450 lbs. (204 kg) or more. Payload includes the driver, passenger,
POLARIS-approved accessories and cargo. Never exceed the stated
load capacity for this vehicle. See page 130.

Adjustment

Cam

Lowest

(Softest)

Setting

Highest

(Stiffest)

Setting
