96

MAINTENANCE

General Maintenance

Carburetor

The number stamped in the end of the main jet indicates the jet size.

The jet installed at the time of manufacture is not necessarily correct for

your elevation.  It's your dealer's responsibility to make sure the correct

main jet is installed.

Carburetor Adjustments

The frequency at which the carburetors are synchronized or balanced is

important.  Properly adjusted carburetors can greatly improve engine

performance, fuel economy, engine life, and reliability.

If you notice any of the following conditions, the carburetor may need

adjustment:
• Hard starting
• Poor idle
• Overheated pistons and cylinder walls
• Plug fouling
• Poor engine response to various throttle valve openings

CAUTION

Operating the snowmobile with incorrect jetting can result in serious engine

damage.  Have your Polaris dealer perform all carburetor adjustments to

ensure all adjustments are done correctly.

97

MAINTENANCE

General Maintenance

Carburetor Water/Sediment Trap

Most Polaris snowmobiles contain patented carburetor bowl water/sedi-

ment traps located at the bottom of each carburetor.  The trap, consisting

of a hose with a plug, should be drained about every 1000 miles (1600

km) and inspected for contamination.

Cleaning Procedure
1. Turn the fuel valve off.
2. Place a container or shop

towels below the plug to

catch drained fuel.

3. Slide the clamp (1) away

from the drain plug (2) and

remove the drain plug from

the sediment tube.

4. Wipe residue from the plug

and reinstall it.  Reposition

and tighten the clamp.

5. Repeat the draining proce-

dure for any remaining traps.

WARNING

When draining the traps, fuel spillage will occur.  Always work in a well venti-

lated area away from anything that may cause the fuel to ignite, such as open

flames, sparks, heaters, trouble lights, cigarettes, etc.  Review the fuel warn-

ings on page 73.

1

2

98

MAINTENANCE

General Maintenance

Coolant

The coolant supplied in the system is a 60/40 mixture of ethylene-glycol

and distilled water.  This mixture provides protection against freezing.

Contact your dealer if greater protection is required.

Use Premium 60/40 anti-freeze coolant, which is already premixed and

ready to use.  Do not dilute with water.  Never exceed a 60% antifreeze/

40% water mixture.   See page 124 for Polaris products.

NOTE: Never add tap water to the cooling system.  Minerals cause

deposits and may react adversely with the metals in the engine

and cooling system.

n

Coolant Level

The engine coolant level is controlled by the recovery system.  The

recovery system components are:
• Coolant bottle or overflow tank
• Engine filler neck
• Pressure cap
• Connecting hoses

Always maintain the coolant level between the minimum and maximum

marks on the coolant bottle (when engine is cold) to prevent overheating

and serious engine damage.

CAUTION

Operating the snowmobile with insufficient coolant will result in overheating

and serious engine damage.  Always maintain the coolant level as recom-

mended.

99

MAINTENANCE

General Maintenance

Coolant High Temperature Indicator Light

The high temperature indicator light will illuminate when engine cool-

ant temperature becomes too hot for safe continued operation of the

engine. If you must drive your machine after the high temperature indi-

cator light has come on, drive slowly and stop frequently to allow the

engine to cool down. Driving in deep snow will also help cool the

engine.  See your dealer for service. Add coolant if the level is low.

NOTE: Engine performance will be reduced if you continue operating

when the high temperature light is on.

Flushing the Cooling System

To ensure that the coolant maintains its ability to protect the engine,

drain the system completely every two years and add a fresh mixture of

antifreeze and distilled water. This service must be performed when the

engine is cold.  Ask your Polaris dealer to check the coolant when he

performs the fall tune-up on your snowmobile.

WARNING

Steam and hot liquids will cause serious burns to your skin.  Never remove

the pressure cap when the engine is warm or hot.
