92

MAINTENANCE

General Maintenance

Spark Plugs

A new engine can cause temporary spark plug fouling due to the preser-

vative added during the assembly process.  Avoid prolonged idle speeds,

which cause plug fouling and carbonization.

Refer to your Owner's Manual Supplement for the specific spark plug to

be used in your machine.

Change the spark plugs every 2000-2500 miles (3200-4000 km).

CAUTION

Using non-recommended spark plugs can result in serious engine damage.

A spark plug with a heat range too high will always cause engine damage if

the engine is operated in conditions more severe than intended for that plug.

Always use the spark plugs recommended for your snowmobile. See your

Owner’s Manual Supplement.
• Use recommended spark plugs with the proper gap.
• Use only resistor-type spark plugs.
• Torque spark plugs to 18-22 ft. lbs. (24-30 Nm).
• Always carry spare spark plugs.

93

MAINTENANCE

General Maintenance

Spark Plug Condition

Spark plug condition is indicative of engine operation.  The spark plug

firing end condition should be read after the engine has been warmed up

and the vehicle has been driven at higher speeds.  Immediately check the

spark plug for correct color.

NOTE: Incorrect fuel mixture can often cause a spark plug to appear

too dark or too light in color.  Before changing spark plug heat

ranges, be sure the correct main jet is installed in the carbure-

tor(s).  Refer to the Owner's Manual Supplement or see your

dealer.

1. Normal

The normal insulator tip is gray, tan or light brown.  There will be few

combustion deposits.  The electrodes are not burned or eroded.  This

indicates the proper type and heat range for the engine and the service.

NOTE: The tip should not be white.  A white insulator tip indicates

overheating, caused by use of an improper spark plug or incor-

rect carburetor/throttle body adjustments.

2. Wet Fouled

The wet fouled insulator tip is black.  A damp oil film covers the firing

end.  There may be a carbon layer over the entire nose.  Generally, the

electrodes are not worn.  General causes of fouling are excessive oil, use

of non-recommended injection oil, improper use of the choke, or incor-

rect carburetion adjustments.

WARNING

A hot exhaust system and engine can cause serious burns. Wear protective

gloves when removing a spark plug for inspection.

94

MAINTENANCE

General Maintenance

Spark Plug Removal and Replacement

1. Remove the spark plug cap.
2. Using the special wrench provided in

the tool pouch, rotate the spark plug

counterclockwise to remove.

3. Reverse the procedure for spark plug

installation.

4. Torque to 18-22 ft. lbs. (24-30 Nm).
5. Reinstall the spark plug cap.

Oil Lines

Inspect oil line condition every 1000 miles (1600 km).

Oil Filter

The oil filter is located at the side of

the oil tank. Have your dealer change

the oil filter and bleed the system

annually or every 1000 miles (1600

km).

NOTE: The direction of the arrows

indicates the direction of

flow through the filter.

95

MAINTENANCE

General Maintenance

Intake Filters

The intake foam filters (

✪)

limit snow ingestion into

the intake system.  When

operating in loose powder

snow, check the foam filters

periodically to remove any

accumulation of snow.

Fuel Pump

All fuel pump service must be performed by an authorized Polaris

dealer.  Do not attempt to service the fuel pump.

Fuel Filter/Fuel Lines

See your Polaris dealer for replacement of the in-tank fuel filter every

1000 miles (or annually).

Inspect the fuel lines regularly for signs of deterioration or damage.

Always check fuel line condition after periods of storage. Normal dete-

rioration from weather and fuel compounds may occur.  Replace worn

or damaged fuel lines promptly.

CAUTION

Operating the snowmobile with the intake filters removed may cause carbu-

retor icing.  The result will be poor fuel economy or carburetor malfunction.

Always reinstall the intake filters before operating the snowmobile.

CAUTION

Kinking the fuel lines or using a pliers or similar tools to remove fuel lines

may cause damage to the lines.  If a fuel line has been damaged or kinked,

replace it promptly.

✪
