TM 10-8400-203-23&P. Manual - part 22

10-8400-203-23&P

0025

0025-1

PARTS INFORMATION

MODULAR SLEEP SYSTEM

10-8400-203-23&P

0025

0025-2

Figure 1. Modular Sleep System.

10-8400-203-23&P

0025

0025-3

(1) (2) (3)

(4)

(5)

(6)

(7)

ITEM
NO.

SMR
CODE

NSN

CAGEC

PART
NUMBER

DESCRIPTION AND USABLE ON
CODE (UOC)

QTY

GROUP 02 MODULAR SLEEP
SYSTEM
FIG. 1 MODULAR SLEEP SYSTEM

8465-01-445-
6274

58536 A-A-55262 MODULAR SLEEP SYSTEM

8465-01-398-
0685

58536 A-A-55262 .SLEEPING

BAG,

PATROL

..LOOP TAPE 4-INCH, COLOR FG 504

..HOOK TAPE, 1 ½-INCH COLOR
FG504

4020-00-262-
2019

81349 MIL-C-5040 ..ZIPPER PULL, MAKE FROM: CORD,

ELASTIC, NYLON, 1/8 INCH
DIAMETER, TYPE II, BLACK.

6 PAOZZ

5340-01-393-
4890

02768 302-0000-5614

..FASTENER, CYLINDER, SPRING
LOADED

7 PAFZZ

4020-00-262-
2019

81349 MIL-C-5040 ..CORD,

ELASTIC, NYLON, 1/8 INCH

DIAMETER, TYPE II, BLACK. CUT TO
38 INCHES

8465-01-398-
0687

58536 A-A-55262 .SLEEPING

BAG,

INTERMEDIATE

COLD WEATHER

..HOOK TAPE, 4-INCH COLOR UG505

..HOOK TAPE, 1 ½-INCH COLOR UG
505

..LOOP TAPE, 4-INCH COLOR UG505

4020-00-262-
2019

81349 MIL-C-5040 ..ZIPPER PULL, MAKE FROM: CORD,

ELASTIC, NYLON, 1/8 INCH
DIAMETER, TYPE II, BLACK.

13 PAOZZ

5340-01-393-
4890

02768 302-0000-5614

..FASTENER, CYLINDER, SPRING
LOADED

14 PAFZZ

4020-00-262-
2019

81349 MIL-C-5040 ..CORD,

ELASTIC, NYLON, 1/8 INCH

DIAMETER, TYPE II, BLACK. CUT TO
38 INCHES

8465-01-398-
5428

58536 A-A-55262 .STUFF

SACK,

COMPRESSION

16 PAOZZ

5340-01-393-
4890

02768 302-0000-5614

..FASTENER, CYLINDER, SPRING
LOADED

10-8400-203-23&P

0025

0025-4

(1) (2) (3)

(4)

(5)

(6)

(7)

ITEM
NO.

SMR
CODE

NSN

CAGEC

PART
NUMBER

DESCRIPTION AND USABLE ON
CODE (UOC)

QTY

17 PAFZZ

4020-00-262-
2019

81349 MIL-C-5040 ..CORD,

ELASTIC, NYLON, 1/8 INCH

DIAMETER, TYPE II, BLACK. CUT TO
38 INCHES

8465-01-416-
8517

99994 PD-95-04 .BIVY

COVER

4020-00-262-
2019

81349 MIL-C-5040 ..ZIPPER PULL, MAKE FROM: CORD,

ELASTIC, NYLON, 1/8 INCH
DIAMETER, TYPE II, BLACK.

20 PAOZZ

5340-01-393-
4890

02768 302-0000-5614

..FASTENER, CYLINDER, SPRING
LOADED

8465-01-393-
6515

58536 A-A-55074 MAT,

SLEEPING, SELF-INFLATING

END OF FIGURE

10-8400-203-23&P

0026

0026-1

PARTS INFORMATION

ARCTIC GEAR

10-8400-203-23&P

0026

0026-2

Figure 1. Arctic Gear.

10-8400-203-23&P

0026

0026-3

(1)

(2) (3)

(4) (5)

(6)

(7)

ITEM
NO.

SMR
CODE

NSN

CAGEC

PART
NUMBER

DESCRIPTION AND USABLE ON
CODE (UOC)

QTY

GROUP 03 ARCTIC GEAR

FIG. 1 ARCTIC GEAR

5465-01-085-1935

58230

TRUCKER
MODEL

SKIS, CROSS COUNTRY

BINDING,

SKI

(LOCAL

PURCHASE:

SILVRETTA ALPINE TOURING
BINDING)

.SCREW,

TAPPING-FF-S-107

.SCREW, TYPE A, CADMIUM PLATED,
STEEL, #8 X 3/8-INCH LONG, SLOTTED,
PAN HEAD

.SCREWS, #7 X 5/8-INCH LONG,
SLOTTED, ROUND HEAD

.SCREW, #12 X 5/8-INCH LONG,
SLOTTED, FLAT HEAD

8465-00-240-2963 81349 MILR43207

.LACES, SKI REPAIR

9505-00-288-6400 81346

ASTM A853

.WIRE, NON-ELECTRICAL

6 MOOO

.EMERGENCY THONG. (MAKE FROM:
CORD, FIBROUS, 4020-00-236-1801,
TWO PIECES CUT 55 INCHES LONG)

8465-00-753-6145

81349

MIL-P-41806

POLE, SKI (53-INCH)

8465-00-753-6142

81349

MIL-P-41806

POLE, SKI (58-INCH)

8465-00-753-5962

81349

MIL-P-41806

.SNOW RING, SKI POLE

5310-00-916-6660

02768

8063-37-01-
0531

..PUSH ON NUT

8465-00-965-2174

81349

MIL-C-1780 SNOWSHOES

8465-00-965-2175 81349 MIL-B-44374

.BINDING ASSEMBLY, SNOWSHOE

8430-01-056-0815

81349

MIL-B-41816

BOOTS, EXTREME COLD WEATHER,
MENS, WHITE, SIZE 3N

8430-01-057-3500

81349

MIL-B-41816

BOOTS, EXTREME COLD WEATHER,
MENS, WHITE, SIZE 4W

8430-00-655-5541

81349

MIL-B-41816

BOOTS, EXTREME COLD WEATHER,
MENS, WHITE, SIZE 5N

10-8400-203-23&P

0026

0026-4

(1)

(2) (3)

(4) (5)

(6)

(7)

ITEM
NO.

SMR
CODE

NSN

CAGEC

PART
NUMBER

DESCRIPTION AND USABLE ON
CODE (UOC)

QTY

8430-00-823-6902

81349

MIL-B-41816

BOOTS, EXTREME COLD WEATHER,
MENS, WHITE, SIZE 5XN

8335-00-131-6538

81348

V-L-61 .LACES,

FOOTWEAR,

WHITE

8430-00-823-7024

81349
