63.7 63 10 150 Removing and installing Bowden cable for headlight beam 63 10 Removing Bowden cable e Attention: Switch off ignition. • Remove the seat. • Remove side panels ( • Remove upper section of fairing ( • Disengage Bowden cable (1) from the headlight. 63 10 Installing and adjusting Bowden cable • Engage Bowden cable (1) at the headlight. • Secure nut (2) with rubber ring (3) and washer (4) • Turn adjuster (5) counter-clockwise as far as it • Adjust play of Bowden cable (1) at headlight to e Attention: Make sure that Bowden cable is not trapped and is • Install the upper section of the fairing. • Install inner trim of fairing. • Turn adjuster (5) counter-clockwise as far as it e Attention: Make sure that lever (6) is not held by Bowden • Slacken Bowden cable (1) at headlight and set to • Check function of headlight beam throw adjust- • Assemble the motorcycle. • Check headlight beam throw, adjust if necessary 63 21 380 Removing and installing rear light cluster See illustration in section on removing and installing R22630030 2 1 5 3 4 6 |
