Motorcycle BMW R1150RT. Manual - part 41

18.4

18.5

18 30

Removing and installing

exhaust system

18 12

Removing and installing silencer

and oxygen sensor

•

Remove fuel tank.

•

Disconnect the oxygen-sensor plug (arrow) and
remove the cable holders.

e

 Attention:

Do not pull the oxygen sensor cable.

•

Slacken the clamp (1).

•

Remove the fasteners securing the rear silencer
to the rear frame section.

•

Remove rear silencer.

•

Remove the oxygen sensor with special socket
wrench insert, BMW No. 11 7 020.

•

Installation is the reverse of the removal proce-
dure.

e

 Attention:

Note position of cable for oxygen sensor.
After a trial run, read out Motronic fault memory.

X

Tightening torque:

Oxygen sensor
(apply Optimoly TA to thread) ....................... 45 Nm
Clamp, rear silencer to manifold
(apply Optimoly TA to clamp seat) ................ 55 Nm
Silencer to footrest plate .............................  35 Nm

R22180010

.

1

11 7 020

R22610030

18.6

18 11

Removing and installing exhaust

manifold

•

Remove side panels.

•

Slacken clamp (1) holding the rear silencer.

•

Remove fasteners securing exhaust manifold (2).

e

 Attention:

Secure rear silencer in such a way that it cannot fall.

•

Remove exhaust manifold.

•

Installation is the reverse of the removal proce-
dure.

L

 Note:

When installing, fit new sealing rings (3).

e

 Attention:

After a trial run, read out Motronic fault memory.
Note position of cable for oxygen sensor.

X

Tightening torque:

Clamp, manifold to front silencer
(apply Optimoly TA to clamp seat) ................ 55 Nm
Exhaust manifold to cylinder head................ 21 Nm

Rs180030

.

1

3

3

2

2

21.1

Contents

Page

21

Technical Data

............................................................................................................................... 3

Removing and installing clutch

............................................................................................5

Removing clutch

..............................................................................................................................5

Removing clutch from vehicle ..............................................................................................................5
Removing clutch from engine  ..............................................................................................................7

Installing clutch

................................................................................................................................7

Installing clutch in engine  ....................................................................................................................7
Installing clutch in vehicle  ....................................................................................................................7

Removing and installing clutch hydraulic line

..............................................................8

Removing and installing clutch slave cylinder

.............................................................9

Filling and bleeding clutch line

........................................................................................... 10

21 Clutch
