Volkswagen Golf / Golf GTI / Jetta. Manual - part 39





15-51





   Compression pressure values





   New: 10...13 bar





   Wear limit: 7.5 bar





   Permissible difference between all cylinders: 3

bar





-  Check DTC memory:







Repair Manual, 2.8 Liter VR6 4V Fuel Injection

& Ignition, Engine Code(s): BDF, Repair Group
01







-  Read readiness code:







Repair Manual, 2.8 Liter VR6 4V Fuel Injection

& Ignition, Engine Code(s): BDF, Repair Group
01







-  Generate readiness code again if DTC memory

has been erased or engine control module
separated from permanent positive supply:







Repair Manual, 2.8 Liter VR6 4V Fuel Injection

& Ignition, Engine Code(s): BDF, Repair Group
01



Cylinder head, servicing

15-52





Valve gear,
servicing

1 - 5 Nm +

1

/

8



turn (45  )
further


2 - Exhaust

camshaft
bearing
cap


 Before

installing
the
bearing
cap 8,
grease
lightly the
contact
surface
with G
052 723
A2



Fig. 2



 Installation

position



Fig. 3



 Installation

sequence



Page

15-69

 ,

Removing
and
installing
camshaft

3 - Seal

 Replace

complete
if leaking

 Oil

contact
surfaces
of seal
lightly
when
installing

Valve gear, servicing

control
housing

 Spread/stretch

seal as little
as possible
when
replacing

 Offset

gaps by
120

Valve gear, servicing

15-53





4 - Exhaust

camshaft

 Check

radial
clearance
with
Plastigage,
Wear limit:
0.1 mm

 Run-out:

max.
0.01 mm

 Checking

axial
clearance



Fig. 1



 Identification

and valve
timing



Fig. 5



 Removing

and
installing



Page

15-69



5 - Control

housing

 Lightly

lubricate
contact
surfaces
of oil seal
when
installing

 Disassembling

and
assembling



Fig. 6





Check
screen of
control
housing
for soiling
before

Valve gear, servicing
