Dacia SuperNova (engine E7J). Manual - part 144
89A
ELECTRICAL DIAGRAMS
89A - 24
Connect. Denomination
Page
101
ELECTRIC LIGHTER
89-138
103 HA ALTERNATOR
89-109
103 HB ALTERNATOR EXCITATION
89-109
104
ANTI-THEFT MECHANISM
89-117
105
ACOUSTIC WARNING
89-125
113
WINDSCREEN WIPER TIMER
89-113
120
UCE INJECTION( for vehicles without AC)
89-89
120
UCE INJECTION( for vehicles with AC)
89-91
121
FOG LAMPS SWITCH
89-132
122
FOG HEADLAMPS SWITCH
89-132
123
LOCKING DOORS SWITCH
89-134
124
BLOWER SWITCH
89-130
125
HAZARD SWITCH
89-134
128
REAR WINDOW DEFROSTING SWITCH
89-133
138
RIGHT REAR DOOR ACTUATOR
89-140
139
LEFT REAR DOOR ACTUATOR
89-140
140
LEFT FRONT DOOR ACTUATOR
89-139
141
RIGHT FRONT DOOR ACTUATOR
89-139
145
WINDSCREEN WIPER-WASHING SWITCH
89-113
146
DETONATION SENSOR
89-101
147
ATMOSPHERIC PRESSURE SENSOR
89-102
149
RPM SENSOR
89-99
155
REVERSE DRIVING CONTACT
89-98
156
HANDBRAKE CONTACT
89-148
160
STOP CONTACT
89-123
163 GA STARTER
89-109
163 AB STARTER EXCITATION
89-110
166
RIGHT LICENSE PLATE LAMP
89-150
167
RIGHT LICENSE PLATE LAMP
89-150
168
DOCUMENTS COMPARTMENT LIGHTING LAMP
89-138
171
AC COMPRESSOR CLUTCH
89-107
172
RIGHT REAR LAMP
89-145
173
LEFT REAR LAMP
89-145
175
LEFT FOG LAMP
89-148
176
RIGHT FOG HEADLIGHT
89-123
177
LEFT FOG HEADLIGHT
89-124
180
LEFT FRONT DOOR CONTACT
89-148
181
RIGHT FRONT DOOR CONTACT
89-148
184
RIGHT FRONT PARKING LAMP
89-124
185
LEFT FRONT PARKING LAMP
89-124
188
COOLING FAN MOTOR ( for vehicles without AC)
89-108
189
RIGHT REAR LOUD SPEAKER
89-144
190
LEFT REAR LOUD SPEAKER
89-144
191
RIGHT FRONT DOOR LOUD SPEAKER
89-141
192
LEFT FRONT DOOR LOUD SPEAKER
89-141
193
INJECTOR 1
89-104
194
INJECTOR 2
89-105
195
INJECTOR 3
89-105
(until 01.06.2001)
WIRE FUNCTIONS INDEX IN CONNECTORS AND COUPLINGS
