LOWER INTERNAL ACCESSORIES

57

57 - 6

DISMOUNTING

Loosen the screws which fix the lower half-case (3) on the steering support and the attach-

ment screws of the lower half-case on the upper half-case (2).

REMOUNTING

Fix the upper half-case (2) on the steering support.
Place the lower  half-case (3) on the upper half-case and fix it by means of four screws.
Fix the lower half-case on the steering support by means of three screws.

STEERING WHEEL AXLE HALF-CASES

      LOWER INTERNAL ACCESSORIES

57

57 - 7

INSIDE REAR VIEW MIRROR

DISMOUNTING
Dismount the rubber buffer (2); from the

rear view mirror rod (1).

Detach from clips  the  sun visors rods from

the inside rear view mirror support;

Dismount the protector support (3).
Dismount the attachment screws (4) of the

rear wiev mirror on the windscreen frame and
release the mirror.

REMOUNTING
Perform the dismounting operations in the

reverse order.

3

2

1

4

LOWER INTERNAL ACCESSORIES

57

57 - 8

DISMOUNTING
Detach the  sun  visors rods from the inside

rear view mirror support.

Dismount the attachment screws (1) on the

windscreen frame and release the sun visors (2).

REMOUNTING
Perform the dismounting operations in the

reverse order.

 SUN VISORS

      LOWER INTERNAL ACCESSORIES

57

57 - 9

DISMOUNTING
Dismount the turning handles attachment

screws (1) from the roof stretcher.

Release the turning handles. (2)

REMOUNTING
Perform the dismounting operations in the

reverse order.

TURNING HANDLES

2

1
