Dacia Solenza (engine E7J). Manual - part 115

57

57  - 12

INSIDE ACCESSORIES

Turning handle

DISMOUNTING

Dismount the screws from points A attaching the turning handle on the body roof.
Release the turning handle.

REMOUNTING

Perform the dismounting operations in  the reverse order.

59

SECURITY ELEMENTS

59 - 1

Front safety belts

1

4

3

2

TIGHTENING MOMENTS(daNm)
Front safety belt attachment screw    2.7

DISMOUNTING

Dismount:

- front/rear door gasket (in the

contact area w ith the middle pillar
covering);

- attachment screws (1) and  (2) of

the  front safety belt to the upper part,
consequently, to the lower part, on the
middle pillar lining;

- middle pillar covering (see chapter

71);

- attachment screw (3) of the safety belt

retriever on the middle pillar lining.

Dismount the  attachment screw (4) of the

safety belt lock on the tunnel.

REMOUNTING

Perform the dismounting operations in the

reverse order, taking into consideration the
following:

- retriever guiding on the centering part

welded on the pillar.

- the required tightening moment of

front the safety belts attachment screws is of
2,7 daNm.

SECURITY ELEMENTS

59

59  - 2

Rear safety belts

4

3

2

1

3

2

1

4

TIGHTENING MOMENTS(daNm)

Rear safety belt attachment screw        2.7

DISMOUNTING

Dismount the two attachment screws of

the bench backrest.

Swing over the bench backrest.
Dismount:

- rear  plate and its supports (see

chapter 74);

- belt attachment screws (2) and (3) on

the side frame lining.

Place back the bench backrest in  normal

position.

Swing over its supports the bench seat.
Dismount the rear belt attachment

screws (4) on the central floor.

REMOUNTING

Perform the dismounting operations in

the reverse order.

The required tightening moment of the

rear belt attachment screws is of 2,7 daNm.

61

HEATING

61 - 1

61

General

1 – heating radiator
2 – cold/warm air flaps control
3 – air repartition flaps control
4 – air repartition control cable
5 – air-mixing control cable
a – air inlet
b – windscreen defogging exit
c – dashboard air vents exit

b

a

3

4

5

2

c

1
