CV JH3 - 051 21 MECHANICAL GEARBOX 21 - 24 INTERNAL CONTROLS MÎ 1-2 3-4 5 The internal control axles must not show any deformations or wear on the milling for locking balls, and their sliding on bearings must be done freely, without excessive clearance. The contact surfaces of the forks with collar of the rocking must not show either deformations nor wear. Ensuring of the control forks axles is performed by means of the balls and springs placed in the holes made in the mechanisms crankcase. The locking of the control axles is done by means of some cylindrical rolls mounted inside the clutch–differential crankcase. Gearbox dismounting |
