CV JH3 - 051 21 MECHANICAL GEARBOX 21 - 20 DIFFERENTIAL The differential of the JH3-051 gearbox is the simple type (with two satellites and two planetary wheels, one of which making a common body with the tulip of the planetary transmission). This differential is supported in the clutch – differential crankcase by means of two cylindrical bearings equipped with balls of various sizes. The two bearings are pressed in the clutch – differential crankcase. DIFFERENTIAL DISMOUNTING This operation is to be performed after separating the crankcases. and a hammer, the sealing gasket (2) is gently hit in order to make it pivoting. The oil seal ring is carefully pulled along the grooved part of the planetary pinion in order not to deteriorate the grooves. Gearbox dismounting |
