MIR-1

DRIVER CONTROLS

C

D

E

F

G

H

I

J

K

M

SECTION

MIR

A

B

MIR

N

O

P

CONTENTS

MIRRORS

COMPONENT DIAGNOSIS ..........................

2

DOOR MIRROR ...................................................

2

Wiring Diagram - Coupe ............................................

2

Wiring Diagram - Sedan ............................................

5

INSIDE MIRROR  .................................................

8

Wiring Diagram  .........................................................

8

SYMPTOM DIAGNOSIS  ..............................

10

SQUEAK AND RATTLE TROUBLE DIAG-
NOSES ...............................................................

10

Work Flow  ...............................................................

10

Generic Squeak and Rattle Troubleshooting  ..........

12

Diagnostic Worksheet  .............................................

14

PRECAUTION ..............................................

16

PRECAUTIONS ..................................................

16

Supplemental Restraint System (SRS) "AIR B
AG" and "SEAT BELT PRE-TENSIONER" ..........

16

PREPARATION ...........................................

17

PREPARATION .................................................

17

Commercial Service Tools .....................................

17

ON-VEHICLE REPAIR .................................

18

INSIDE MIRROR  ...............................................

18

Exploded View .........................................................

18

Removal and Installation  .........................................

18

DOOR MIRROR  ................................................

19

Exploded View .........................................................

19

Removal and Installation  .........................................

19

DISASSEMBLY AND ASSEMBLY ..............

20

DOOR MIRROR  ................................................

20

Exploded View .........................................................

20

Disassembly ............................................................

20

Assembly .................................................................

21

DOOR MIRROR COVER  ...........................................

21

DOOR MIRROR COVER : Disassembly  .................

21

DOOR MIRROR COVER : Assembly ......................

21

MIR-2

< COMPONENT DIAGNOSIS >

DOOR MIRROR

COMPONENT DIAGNOSIS

DOOR MIRROR

Wiring Diagram - Coupe

INFOID:0000000004205281

ALLWA0002GB

DOOR MIRROR

MIR-3

< COMPONENT DIAGNOSIS >

C

D

E

F

G

H

I

J

K

M

A

B

MIR

N

O

P

ALLIA0001GB

MIR-4

< COMPONENT DIAGNOSIS >

DOOR MIRROR

AWLIA0152GB
