Frelander 2. Manual - part 746

Telephone

262

L

No call

Dialling

Incoming call

Call in progress

Making telephone calls

Dialling a number manually

Enter the telephone number to be dialled, using
the vehicle keypad. The digits of the number
appear in the display.

To pause during number entry, press and hold
the AUTO key. A * symbol will appear in the
display.

The international dial symbol + can be entered
by pressing and holding the 0 (zero) key.

When the telephone number has been entered,
briefly press the ENTER button or operate the
answer call switch on the steering wheel to dial
the number (Dialling appears in the display
supported by ringing tones). A successful
connection is shown on the display.

Ericsson T39

14 : 54

E83789

Dialling...

Andrew Work

CANCEL

E83790

Answer?

Andrew Work

YES

NO

E83791

00:17:04

Andrew Work

END

MENU

E83792

DIAL

CLEAR

>0192664

Dialling...

01926648100

CANCEL

00:00:00

01926648100

END

MENU

E83793

Dialling...

263

Telephone

R

Note: To cancel a call at any time, press the
EXIT button or operate the end call button on
the steering wheel.

Correcting or deleting numbers

If an incorrect digit is entered, press the EXIT
button (arrowed) to delete the last digit, then
enter the correct digit.

Press and hold the EXIT button (for
approximately two seconds) to delete all
entered digits.

Multiple choice dialling

If the number you have dialled has an
automated voice that requests another
number, for a different area or department, use
the keypad to enter that number.

Last number redial

The last number dialled can be redialled using
the answer call switch on the steering wheel. If
telephone mode is active, pull and release the
switch. The number will appear in the audio
unit display. Pull and release the answer call
switch for a second time and the number will
be dialled.

If telephone mode is not active, press the
telephone mode button to enter telephone
mode.

Note: Some mobile telephones reverse the last
dialled number list, which results in the last
dialled number being at the bottom of the list,
rather than the top.

Ending telephone calls

To end a telephone call, press the EXIT button
or operate the end call switch on the steering
wheel.

DIAL

CLEAR

>0192664

E83795

00:03:14

Andrew Work

END

MENU

E83796

Telephone

264

L

Receiving telephone calls

When a call is received, the number or caller ID
(if entered into the phone book) will appear in
the audio unit display.

If the audio or a CD was in use before the
telephone call then that function will resume at
the end of the phone call. A CD will continue
playing from the point at which it was paused
by the telephone call. The telephone display will
be visible for the duration of the call.

The call can be answered in two ways:
• Operate the answer call switch on the

steering wheel (arrowed in inset).

• Briefly press the ENTER button (arrowed).

If automatic answer is switched on, the call is
accepted automatically. If automatic answer is
switched off, and you do nothing, the vehicle
system will operate as your mobile telephone
would operate, i.e. go to voice mail or continue
ringing.

Note: The automatic answer feature can be
switched on or off.  See TELEPHONE SETUP
(page 258).

When the call is accepted, the display shows
that the call is in progress and the duration of
the call in minutes and seconds.

Rejecting an incoming call

To reject a call without answering, briefly press
the EXIT button or operate the end call switch
on the steering wheel.

YES

NO

Jenny

Answer?

E83797

YES

NO

Jenny

Answer?

E83798

265

Telephone

R

Telephone in-call menu

A number of settings can be made while a call
is in progress. These are:
• muting the call
• privacy call
• accessing the phonebook.
When the call is ended the in-call settings
return to their default values.

To enter the in-call menu, press the MENU
button and then rotate the ENTER button to
highlight the required option. Press the ENTER
button to select.

Mute the call

Select Mute and press the ENTER button, this
will prevent the caller from hearing any
conversation in the vehicle.

Select Mute Off and press the ENTER button to
resume your telephone conversation.

Privacy mode

Select Privacy and press the ENTER button,
this will transfer the call to the mobile
telephone preventing the vehicle occupants
from listening in to your received conversation.

Select Hands Free and press the ENTER button
when you wish to return to using the vehicle
system.

Note: Some mobile telephones may end the
call or lose the Bluetooth connection when
transferring between Privacy and Hands Free
modes.

Phone book

You can access your phone book during a
telephone conversation if you need to find a
particular number.

Select Phonebook and press the ENTER
button.

Press the EXIT button to return to your
telephone conversation.

00:17:04

Andrew Work

END

MENU

SELECT

EXIT

Phonebook

Privacy

Mute

E83801
