Frelander 2. Manual - part 745

Telephone

258

L

TELEPHONE SETUP

Telephone main menu

Press the MENU button then rotate the ENTER
button to select from:
• Missed calls
• Received calls
• Dialled calls
• Phonebook

•  See PHONEBOOK (page 266).

• Bluetooth

•  See BLUETOOTH SETUP (page 256).

• Phone settings
• Clock

•  See CLOCK (page 107).

Press the ENTER button to confirm your
selection.

Missed calls

The audio unit display will list the numbers of
the last 10 calls which have been missed.
These are displayed in chronological order,
with the last number missed first and
highlighted.

Note: Some mobile telephones reverse the
missed call list, which results in the last missed
call number being at the bottom of the list,
rather than the top.

 Rotate the ENTER button to select the number,
then press again or operate the answer call
switch on the steering wheel to dial the
number.

If there are no entries, an empty list is shown,
press EXIT to return to the phone view.

Note: When viewing missed calls, do not rotate
the volume button as this will result in your
highlighted selection returning to the first entry
in the list, irrespective of your previously
highlighted position.

Received calls

The audio unit display will list the numbers of
the last 10 calls which have been received.
These are displayed in chronological order,
with the last number received first and
highlighted.

Note: Some mobile telephones reverse the
received call list, which results in the last
received call number being at the bottom of the
list, rather than the top.

 Rotate the ENTER button to select the number,
then press again or operate the answer call
switch on the steering wheel to dial the
number.

If there are no entries, an empty list is shown,
press EXIT to return to the phone view.

14 : 54

Ericsson T39

SELECT

EXIT

Phonebook..

Dialled Calls..

Bluetooth..

E83808

259

Telephone

R

Note: When viewing received calls, do not
rotate the volume button as this will result in
your highlighted selection returning to the first
entry in the list, irrespective of your previously
highlighted position.

Dialled calls

The audio unit display will list the numbers of
the last 10 calls which have been dialled. These
are displayed in chronological order, with the
last number dialled first and highlighted.

Note: Some mobile telephones reverse the
dialled call list, which results in the last dialled
call number being at the bottom of the list,
rather than the top.

The dialled calls list can also be accessed by
pressing the ENTER button, when telephone
mode is selected.

 Rotate the ENTER button to select the number.
Then to dial the number, press ENTER again, or
operate the answer call switch on the steering
wheel.

If there are no entries, an empty list is shown,
press EXIT to return to the phone view.

Note: When viewing dialled calls, do not press
the volume button as this will take you back to
the radio or CD.

Phone settings

Select Call options from the Phone Settings
menu, and press the ENTER button.

Call options

This feature is used to turn the automatic
answer facility on or off and also to enter the
voice mail number.

Rotate the ENTER button to highlight
Automatic answer and press the ENTER
button. Select On and press the ENTER button
again.

When automatic answer is on, all incoming
calls are answered automatically and when the
mode is off you must accept the call or press
EXIT to reject.

To enter a voice mail number, rotate the ENTER
button to highlight Voicemail number and
press the ENTER button. Enter your voice mail
number on the keypad and press the ENTER
button again.

Use the EXIT button to delete an incorrect
number.

SELECT

EXIT

Automatic answer

Voicemail number

E83809

Telephone

260

L

Sounds and alerts

Selecting sounds and alerts gives you the
choice to alter the ring tone and the ring
volume.

To select the ring volume, rotate the ENTER
button to highlight Ring volume and then
press the ENTER button to select. Now by
rotating the On or off or volume button you can
change the ring volume.

Note: If the ring volume is not changed, the
ring tone will sound for eight seconds. If the
ring volume is changed, the ring tone will
return to the menu two seconds after the
change has been made.

This only applies to the Car ring tones. If
Mobile ring tone is selected, no ring tone will
be played. When Mobile ring tone has been
selected, the volume can only be changed
when there is an incoming call, i.e. ringing.

Select ring tone by rotating the ENTER button
to highlight Ring tone and then press the
ENTER button to select. Rotate the ENTER
button to select one of the four alternative ring
tones, or use the mobile telephone ring tone.
Once you have selected a ring tone, press the
ENTER button to hear the selected ring tone.

Note: This only applies to the Car ring tones. If
Mobile ring tone is selected, no ring tone will
be played. When Mobile ring tone has been
selected, the volume can only be changed
when there is an incoming call, i.e. ringing.

SELECT

EXIT

Sounds and alerts..

Call options..

AutoCopy Ph.Book..

E83810

Ring
Volume

27

E83811

Ring
Volume

Mute

Ring
Volume

Max

SELECT

EXIT

Car ring tone 1

Car ring tone 2

Mobile ring tone

YES

NO

Car ring tone 1

Store:

E83812

261

Telephone

R

Another brief press of the ENTER button will
store the tone. If you press the EXIT button the
tone will not be stored and the ring tone menu
will remain visible. Press the EXIT button again
to return to the main menu or to the function
previously selected.

Note: Not all mobile telephones support
Mobile ring tone, in this case it will not be
possible to select and store the Mobile ring
tone setting in the vehicle system.

Autocopy phonebook

This feature allows you to choose whether or
not your phone book is automatically updated
every time you connect your telephone to the
vehicle system. If On is selected and your
telephone has the capability, the vehicle phone
book will be updated the next time the
telephone is connected to the vehicle. If Off is
selected the phone book will not be
downloaded to the vehicle system.  See
PHONEBOOK (page 266).

Press the ENTER button after making your
selection. Pressing the EXIT button will return
you to the previous screen. To return to the
telephone main display, press and hold the
EXIT button.

USING THE TELEPHONE

Selecting telephone mode

Switch on the ignition. If your telephone is
switched on and previously paired or
connected with the system, you can select the
vehicle telephone system.

Briefly press the telephone mode button
(arrowed). Visual confirmation of telephone
operation is given via the display.

If a telephone is not paired to your vehicle
system, No paired Phone and Do you want to
pair? is displayed.  See BLUETOOTH SETUP
(page 256).

To exit telephone mode, press one of the audio
system mode buttons, i.e. FM, AM or CD or
AUX.

Telephone display

There are four different call status screens:

SELECT

EXIT

On

Off

E83813

14 : 54

ricsson T39

E83788
