Frelander 2. Manual - part 747

Telephone

266

L

Voice mail

Voice mail may be set up by your service
provider and can be used by the vehicle
system.

Before voice mail can be used in the vehicle
system, the voice mail number needs to be
entered.  See TELEPHONE SETUP (page 258).

You can access your voice mail when the
mobile telephone is switched on, the voice mail
number has been stored in the vehicle system
and the vehicle system is in telephone mode.
Press and hold the number 1 key on the
keypad. This will send a message to the mobile
telephone to dial the voice mail number.

You can also access voice mail by using Call
options in the Phone Settings menu.  See
TELEPHONE SETUP (page 258).

The audio unit display will indicate when voice
mail is empty.

PHONEBOOK

When your telephone is next connected to the
vehicle and autocopy phonebook is set to On,
your phonebook is downloaded automatically
to the vehicle system, provided your telephone
has the capability.  See TELEPHONE SETUP
(page 258).

Note: If there is a communication problem with
the telephone or the telephone does not
support this feature, the message Phonebook
is empty will be displayed, and the phonebook
will not be downloaded.

14 : 54

Ericsson T39

ENTER

EXIT

number
>

Enter voicemail

ENTER

CLEAR

number
>1234567890

Enter voicemail

Dialling...

Voicemail

CANCEL

E83803

14 : 54

Ericsson T39

Dialling...

Voicemail

CANCEL

E83804

267

Telephone

R

Once downloaded, the phonebook can be
accessed through the telephone main menu.

1. Press the MENU button to access the

telephone main menu.

2. Rotate the ENTER button to highlight

Phonebook and press the ENTER button
again to select.

Note: To exit the phonebook without selecting
an entry, press the EXIT button.

Phonebook menu

Rotate the ENTER button to select one of the
following options:
• Search Phonebook
• Copy from Phone
• Erase car entry
• Erase car Ph.book
Press ENTER to confirm your selection.

Search Phonebook

Note: When viewing the phonebook, do not
rotate the volume button as this will result in
your highlighted selection returning to the first
entry in the phonebook, irrespective of your
previously highlighted position.

The following methods can be used to search
the phonebook:
• browsing
• alphabetic search
• quick search

Browsing the phonebook

1. With phonebook displayed, rotate the

ENTER button clockwise, or operate the
menu next button on the steering wheel to
scroll down the phonebook. To scroll up
the phonebook, rotate the ENTER button
counterclockwise or press the menu
previous button on the steering wheel.

2. Once the chosen phonebook entry is

highlighted, press the ENTER button, or
operate the answer call switch on the
steering wheel, to dial the number.

SELECT

EXIT

Phonebook

Dialled calls

14 : 54

Ericsson T39

Bluetooth

E83805

SELECT

EXIT

Donna

David

Darren

Dialling...

David

CANCEL

E83806

Telephone

268

L

3. If an entry was selected by mistake, either

operate the end call switch on the steering
wheel, or press the EXIT button to cancel
dialling.

Alphabetical search

1. With the phonebook displayed, press the

appropriate key the corresponding number
of times according to the initial letter of the
entry.
• For example; if the initial letter of the

required phonebook entry is H, press the
4 key on the keypad twice. The display
will now show all entries beginning with
the letter H.

2. If there are a large number of entries

beginning with the letter H, the second and
subsequent characters of the name can be
added by repeatedly pressing the relevant
key until the character appears in the audio
unit display.
• For example; if the required phonebook

entry is Helen, press the 4 key on the
keypad twice the 2 key on the keypad
twice, and the 5 key on the keypad three
times. The display will now show all
entries beginning with Hel.

3. Once the chosen phonebook entry is

highlighted, press the ENTER button, or
operate the answer call switch on the
steering wheel, to dial the number.

Dialling...

Helen

CANCEL

SELECT

EXIT

Home

Helen

Harry

E83807

269

Telephone

R

Quick search

1. To find a specific number from your

phonebook without accessing the
phonebook, while in telephone mode,
press and hold a key (between 2-9) which
corresponds to the first letter of the name.
•  For example; if the initial letter of the

required phonebook entry is an M, press
and hold the 6 key of the keypad. The
phonebook will open at the selected
point.

2. If there are a large number of entries

beginning with letter M, the second and
subsequent characters of the name can be
added by repeatedly pressing the relevant
key until the character appears in the audio
unit display.
• For example; if the required phonebook

entry is Mark, press the 2 key on the
keypad once and the 7 key on the keypad
three times. The display will now show
all entries beginning with Mar.

3. Once the chosen phonebook entry is

highlighted, press the ENTER button, or
operate the answer call switch on the
steering wheel to dial the number.

Copy from phone

If the phonebook in the vehicle system does
not match that of the mobile telephone (and
your mobile telephone supports this feature),
the following procedure will allow you to
resynchronise.

Note: The vehicle system phonebook allows
750 entries to be downloaded. If your mobile
telephone contains more than this, the mobile
telephone will send these in memory location
order. Which means that your telephone
phonebook may not always match the vehicle
system.

1. Enter the phonebook menu and select

Copy from Ph. book. Press the ENTER
button to confirm.

2.  If successful, Phonebook downloading to

the car is in progress will appear on the
display.

3. On completion of the download, the

display will return to the telephone main
menu.

If the phonebook download is not supported,
the message Phonebook download is not
supported by this phone will appear in the
display.

Erase car entry

Once a phonebook has been downloaded,
individual entries can be erased from the
vehicle system, not from the mobile telephone.

Note: If Autocopy phonebook is switched on,
the next time the telephone is connected to the
vehicle system, the mobile telephone's
phonebook will be sent to the vehicle. This may
result in your previously deleted entry being
re-instated in the vehicle system phonebook.

14 : 54

Ericsson T39

SELECT

EXIT

Neil

Mark

E83840
