CHASSIS AND BODY DIMENSIONS

BODY DIMENSIONS

77-1-7

Front end information

I.D

Description

X

Y

Z

A

Grille mounting slot

-3190.5

413.9

303

(-125.610)

(16.295)

(11.929)

B

Headlamp mounting panel,

-3124

686.6

335

slot

(-122.992)

(27.031)

(13.188)

C

Bonnet locking platform, jig

-3065.8

611

584.7

location hole

(-120.700)

(24.055)

(23.019)

D

Valance upper, jig location

-2789.4

770.5

507.1

hole

(-109.818)

(30.334)

(19.964)

E

First wing fixing hole

-3064.8

768

650.4

(-120.661)

(30.236)

(25.606)

F

Second wing fixing hole

-2787.9

778.7

686.1

(-109.759)

(30.657)

(27.011)

G

Third wing fixing hole

-2523.9

785.4

704.5

(-99.366)

(30.921)

(27.736)

H

Fourth wing fixing hole

-2259

789.6

718.4

(-88.937)

(31.086)

(28.283)

J

Fifth wing fixing hole

-1993.9

793

728.9

(-78.5)

(31.220)

(28.696)

M77 1753

B

C

D

E

F

G

H

J

A

CHASSIS AND BODY DIMENSIONS

77-1-8

BODY DIMENSIONS

Front end/side information

I.D

Description

X

Y

Z

A

Bonnet hinge fixing, top hole

-1906.3

706

742.9

(-75.051)

(27.795)

(29.248)

B

Windscreen finisher, top slot

-1508.9

715

1229

(-59.405)

(28.147)

(48.385)

C

'A' post top, top hinge fixing

-1859

809.6

584.7

hole

(-120.700)

(24.055)

(23.019)

D

'A' post bottom, top hinge

-1859

809.6

289.1

fixing hole

(-120.700)

(24.055)

(11.381)

E

'B/C' post top, top hinge

-860.5

809.8

680.5

fixing

(-33.877)

(31.881)

(26.791)

F

'B/C' post top, jig location

-841.5

809.8

644.5

hole

(-33.129)

(31.881)

(25.374)

G

'B/C' post bottom, top hinge

-860.5

809.8

290.3

fixing hole

(-33.877)

(31.881)

(11.429)

H

'B/C' post bottom, jig location

-841.5

809.8

254.2

hole

(-33.129)

(31.881)

(10.007)

J

'D' post, door striker fixing,

-75.4

782.3

619.1

top hole

(-2.968)

(30.799)

(24.374)

M77 1755A

B

C

H

F

D

J

A

E

 G

CHASSIS AND BODY DIMENSIONS

BODY DIMENSIONS

77-1-9

Point to point dimensional information
Figures shown outside brackets are metric measurements (millimetres) and those inside brackets are imperial
measurements (inches).

All dimensions are to hole/slot centres.

Front end information

I.D

Description

Length

A

Distance between headlamp mounting panel slots

1373.2 (54.062)

B

Distance between grille locating slots

827.8 (32.590)

C

Distance between bonnet locking platform jig location
holes

1222 (48.110)

D

Distance between valance upper assembly jig location
holes

1541 (60.669)

E

Distance between wing, front fixing holes

1536 (60.472)

F

Distance between bonnet locking platform jig location
hole and wing, front fixing hole

170.2 (6.700)

G

Distance between wing, front fixing hole and wing, rear
fixing hole

1894.7 (74.594)

H

Distance between wing, rear fixing holes

1586 (62.440)

M77 1752

A

B

 C

D

 E

 F

 G

H

CHASSIS AND BODY DIMENSIONS

77-1-10 BODY DIMENSIONS

Front end/side information

I.D

Description

Length

A

Distance between bonnet hinge fixing top hole and
windscreen side finisher top fixing slot

1553.5 (61.161)

B

Distance between windscreen side finisher top fixing
slots

1430  (56.299)

C

Distance between front door top hinge fixing hole and
rear door top hinge fixing hole

998.5 (39.311)

D

Distance between front door top hinge fixing hole and
rear door bottom hinge fixing hole

1067.7 (42.035)

E

Distance between front door bottom hinge fixing hole
and rear door top hinge fixing hole

1072.5 (42.224)

F

Distance between front door bottom hinge fixing hole
and rear door bottom hinge fixing hole

998.5 (39.311)

G

Distance between 'B/C' post top jig location hole and 'D'
post top door striker fixing hole

767 (30.196)

H

Distance between 'B/C' post bottom jig location hole and
'D' post top door striker fixing hole

849.1 (33.429)

M77 1754

A

B

C

D

G

E

 F

 H
