Defender Electric Diagrams. Manual - part 172

C1310

CONNECTOR

DEFENDER 1999 MY

Wing harness to washer
pump link harness

Male
BLUE

Behind LH headlamp

P5577

C1308

C0021

C0008

C1309

C1310

C1307

Cav

Col

CCT

1

B

ALL

2

BLG

ALL

CONNECTOR

C1311

DEFENDER 1999 MY

ECU - Speed (Gulf states
only)

Female
LIGHT GREY

Behind instrument pack

P5770

C0058

C1311

Cav

Col

CCT

1

WG

4

2

B

4

3

YK

ALL

4

BK

4

5

WP

4

C1494

CONNECTOR

DEFENDER 1999 MY

Switch - Blower

Female
WHITE

Behind LH side of fascia

P5819

C1494

C0275

Cav

Col

CCT

2

W

1

3

UK

1

4

RB

1

5

U

1

6

UB

1



Defender

Electrical Reference Library

JLR 12 61 10_1E

Published by Land Rover

© Land Rover 2007
