Defender Electric Diagrams. Manual - part 170

C1268

CONNECTOR

DEFENDER 1999 MY

Relay - Compressor clutch -
Air conditioning (A/C) - Td5

Female
YELLOW

Beneath RH seat

P5596

C1268

C0019

C0508

C0215

C0063

Cav

Col

CCT

30

NS

1

85

NO

1

85

WG

1

86

BS

1

86

WK

1

87

BG

1

CONNECTOR

C1273

DEFENDER 1999 MY

Unit - Air conditioning (a/c)

Female
Natural

Behind RH side of fascia

P5657

C1273

Cav

Col

CCT

1

P

1

3

UN

1

4

RW

1

5

B

1

6

NG

1

7

BW

1

8

BW

1

10

U

1

11

WG

1

13

UB

1

14

O

1

C1294

CONNECTOR

DEFENDER 1999 MY

Illumination - Heater control
- LH

Female
TIN-PLATE

Behind instrument pack

P5761

C1294

C1061 C1054

C1052

C1200

Cav

Col

CCT

1

B

ALL

CONNECTOR

C1305

DEFENDER 1999 MY

Trailer pick-up

Male
BLACK

Below RH rear wheelarch

P5582

C0929

C1260

C1305

C1306

C1095

C0942

C0350

Cav

Col

CCT

1

P

ALL
