C1306

CONNECTOR

DEFENDER 1999 MY

Trailer pick-up

Male
BLACK

Below RH rear wheelarch

P5582

C0929

C1260

C1305

C1306

C1095

C0942

C0350

Cav

Col

CCT

1

P

ALL

CONNECTOR

C1307

DEFENDER 1999 MY

Pump - Washer -
Windscreen

Female
RED

Behind LH headlamp

P5577

C1308

C0021

C0008

C1309

C1310

C1307

Cav

Col

CCT

1

B

ALL

2

LGB

ALL

C1308

CONNECTOR

DEFENDER 1999 MY

Wing harness to washer
pump link harness

Male
RED

Behind LH headlamp

P5577

C1308

C0021

C0008

C1309

C1310

C1307

Cav

Col

CCT

1

B

ALL

2

LGB

ALL

CONNECTOR

C1309

DEFENDER 1999 MY

Pump - Washer - Rear
screen

Female
BLUE

Behind LH headlamp

P5577

C1308

C0021

C0008

C1309

C1310

C1307

Cav

Col

CCT

1

B

ALL

2

BLG

ALL
