Remove screws (1) and remove power takeoff (2). Figure 30 Figure 31 107972 F3B engine assembly To assembly again the engine inverting the described PISTONS MAIN DATA ON PISTONS, PISTONS RINGSAND PIN * Dimension detected on 112 mm ∅. - Y measured from outer ∅ at : A (AEGOETZE) = 2 mm - B (DANA) = 1.5 mm : X = 0.7 ± 0.1 108389 SECTION 2 - APPLICATION G-DRIVE 29 |
