Figure 71 Fit the intake manifold (1) and tighten the fixing screws (2) to the Figure 72 Figure 73 Figure 74 99264 Tightening the fixing screws to the prescribed torque, mount: - the starter motor (1); - the control unit (2) and its support; - the oil dipstick (3) in the crankcase. Check the state of the flexible elements of the 99263 Fit heat exchanger (2) with its respective gasket, then tighten Fit the oil filters (1) on the relevant supports as follows: - oil the seals; - screw the filters down for the seals to make contact with - tighten the filters to a torque of 35 to 40 Nm. 101605 455361 DIAGRAM OF HEAT EXCHANGER FIXING SCREWS TIGHTENING SEQUENCE NOTE 24 SECTION 3 - INDUSTRIAL APPLICATION |
