4C–22 DRIVE SHAFT SYSTEM Reassembly 1. Install DOJ case to bracket. the specified torque. Torque: 116 N·m (85 lb ft) 5. Apply 150g of the specified grease in BJ . installation then install bellows. 8. Install band. Note the setting direction. After installation, check that the bellows is free from 412RS017 9. Install another bellows and fix band. 10. Install the ball guide with the smaller diameter side ahead onto the shaft. 11. Install ball retainer. 12. Using snap ring pliers, install the snap ring (1) securing the ball retainer to the shaft. 412RS013 13. Align the track on the ball (1) retainer with the window in the cage, and install the six balls into position. 412RS018 |
