DIFFERENTIAL (FRONT) 4A1–6 3. Remove the drain bolt to drain differential oil. NOTE: a. During the work, be sure that the diff case is supported by the jack. 412RS003 b. Remove the brake caliper fixing bolt and hang the caliper. Refer to Disc Brakes in Brake section. c. Remove the antilock brake system speed sensor. Refer to Front Wheel Speed in Brake section. 4. Remove the hub assembly (Disc, back plate and knuckle), refer to Front Hub and Disc in this section. 5. Disconnect the knuckle and the suspension arm. Refer to Suspension section. 6. Remove steering link and arm assembly, refer to Steering Linkage in Steering section. 7. Remove suspension crossmember. in this section. 9. Remove protector. 10. Remove breather hose. 11. Remove the hose clip. 12. Disconnect breather hose from front drive axle tube and disconnect housing. 13. Disconnect vacuum hose from actuator. 14. Disconnect shift switch connector. 412RS031 15. Remove VSV assembly (1). NOTE: Be sure not to remove hose and connector from 412RW002 |
