LIGHTING SYSTEM

8A–15

Dome Light Bulb (SWB)

Removal

1. Disconnect the battery ground cable.
2. Remove the lens (2).
3. Remove the bulb (1).

D

Pull out the bulb.

805RX001

Installation

To install, follow the removal steps in the reverse order.

Courtesy Light Bulb

Removal

1. Disconnect the battery ground cable.
2. Remove the lens (2).
3. Remove the bulb (1).

D

Pull out the bulb.

825RW076

Installation

To install, follow the removal steps in the reverse order.

8A–16

LIGHTING SYSTEM

Spotlight Bulb

Removal

1. Disconnect the battery ground cable.
2. Remove the lens (2).
3. Remove the bulb (1).

D

Pull out the bulb.

825RW105

Installation

To install, follow the removal steps in the reverse order.

Luggage Room Light Bulb (LWB)

Removal

1. Disconnect the battery ground cable.
2. Remove the lens (2).
3. Remove the bulb (1).

D

Pull out the bulb.

825RW077

Installation

To install, follow the removal steps in the reverse order.

LIGHTING SYSTEM

8A–17

Luggage Room Light Bulb (Resin Top Model)

Removal

1. Disconnect the battery ground cable.
2. Remove the lens (2).
3. Remove the bulb (1).

D

Pull out the bulb.

805RX002

Installation

To install, follow the removal steps in the reverse order.

HVAC Bezel Illumination Light Bulb

Removal and Installation

Refer to Control Panel Illumination bulb in Heating,
Ventilation and Air Conditioning (HVAC) section.

8A–18

LIGHTING SYSTEM

Shift Lever Illumination Light Bulb (A/T)

Removal

1. Disconnect the battery ground cable.
2. Remove the console assembly.

D

Remove four screws.

3. Remove the bulb (1).

D

Turn the bulb socket counterclockwise.

D

Pull out the bulb from the socket.

825RW078

Installation

To install, follow the removal steps in the reverse order.

Vanity Mirror Illumination Light Bulb

Removal

1. Disconnect the battery ground cable.
2. Remove the lens (1).
3. Remove the bulb (2).

D

Attach some scotch tape to the bulb and pull it out.

743RW005

Installation

To install, follow the removal steps in the reverse order.
