Infiniti Q45 (FY33). Manual - part 384





SEL583VA

SEL584V

INDICATOR LAMPS CHECK

CHECK POWER SUPPLY FOR INDICA-
TOR LAMPS.
Check voltage between IVCS switch ter-
minal

q

1

and ground.

Does battery voltage exist?

Yes

E

No

Check the following.

I

10A fuse [No.

27

,

located in fuse block
(J/B)]

I

Harness for open or
short between fuse and
IVCS switch

CHECK INDICATOR LAMPS.
1. Disconnect IVCS unit connector (Con-

trol unit connector).

2. Apply ground to IVCS switch each ter-

minal and check illumination.

OK

E

NG

Replace IVCS switch
assembly.

Check harness for open or short between
indicators and IVCS unit.

Indicator

Terminal

Redial

q

8

No service

q

9

Mayday

q

10

Information

q

11

GI

MA

EM

LC

EC

FE

AT

PD

FA

RA

BR

ST

RS

BT

HA

IDX

INFINITI COMMUNICATOR (IVCS)

Trouble Diagnoses (Cont’d)

H

H

EL-527

SEL468W

SEL521V

IVCS SWITCH CHECK

CHECK IVCS SWITCH INPUT
SIGNAL.

1. Turn ignition switch “ON”.
2. Select “SWITCH MONITOR” in “DATA

MONITOR” mode.

3. Check each switch signal.

When MAYDAY/INFORMATION switch
is pushed:
MAYDAY/INFORMATION

ON

When MAYDAY/INFORMATION switch
is released:
MAYDAY/INFORMATION

OFF

NOTE:
When CONSULT-II “Data mode” is
operating, INFINITI Communicator does
not dial to Communicator Response
Center when the switches are operated.

NG

E

OK

IVCS switch is OK.

CHECK IVCS SWITCH.
1. Disconnect IVCS switch.
2. Check continuity between IVCS switch

terminals.

NG

E

OK

Check the following:

I

IVCS switch ground cir-
cuit

I

Harness for open or
short between IVCS
switch and IVCS unit.

Replace IVCS switch assembly.

Terminals

Condition

Continuity

q

6

-

q

3

Mayday switch
is turned ON.

Yes

Mayday switch
is OFF.

No

q

7

-

q

3

Information
switch is turned
ON.

Yes

Information
switch is OFF.

No

INFINITI COMMUNICATOR (IVCS)

Trouble Diagnoses (Cont’d)

H

H

EL-528

SEL468W

SEL653V

DRIVER’S OUTSIDE DOOR HANDLE SWITCH CHECK

CHECK OUTSIDE DOOR
HANDLE SWITCH INPUT SIG-
NAL.

1. Turn ignition switch “ON”.
2. Select “SWITCH MONITOR” in “DATA

MONITOR” mode.

3. Check the switch operation.

When driver side outside door handle is
pulled:
DR HANDLE

ON

When driver side outside door handle is
released:
DR HANDLE

OFF

NOTE:
When CONSULT-II “Data mode” is
operating, INFINITI Communicator do
not dial to Communicator Response
Center when the switches are operated.

NG

E

OK

Driver’s door outside
handle switch is OK.

CHECK OUTSIDE DOOR HANDLE
SWITCH.
1. Disconnect driver side door key cylinder

switch connector. (outside door handle
switch connector is combined with the
key cylinder switch.)

2. Check continuity between the door key

cylinder switch terminal

q

1

and

q

2

.

NG

E

OK

Check the following.

I

Outside door handle
switch ground circuit

I

Harness for open or
short between outside
door handle switch and
IVCS unit.

Replace outside door handle switch.

Outside door handle

switch condition

Continuity

Pulled

Yes

Released

No

GI

MA

EM

LC

EC

FE

AT

PD

FA

RA

BR

ST

RS

BT

HA

IDX

INFINITI COMMUNICATOR (IVCS)

Trouble Diagnoses (Cont’d)

H

H

EL-529

REMOTE DOOR UNLOCK FUNCTION CHECK
(CONSULT-II “FUNCTION CHECK” MODE)

Description

“Remote door unlock function” can be checked using CONSULT-
II. Driver side door can be unlocked according to the commands to
the door LCU by the IVCS unit.
Note:
Before performing the function check, confirm that power
door lock system operates properly.

SEL450W

How to perform function check.

1.

Lock the doors with door lock/unlock switch on driver’s door
trim.

2.

Touch “FUNCTION CHECK”.

3.

Touch “DOOR UNLOCK”.

SEL451W

4.

Touch “START”. Then driver side door will be unlocked.

I

If the door cannot be unlocked using CONSULT-II, check har-
ness for open or short between rear LH door control unit
(LCU04) terminal

q

2

and IVCS unit terminal

q

32

.

SEL452W

STOLEN VEHICLE TRACKING/ALARM NOTIFICATION
SETTING CHECK (CONSULT-II “CONFIGURATION”
MODE)

CHECK SYSTEM SETTING.

1. Turn ignition switch “ON”.
2. Select “VHCL TRACKING” or “ALARM

NOTIFICATION” in “CONFIGURATION”
mode.

3. Check the function setting.

I

“ON” shows the function is activated.

I

“OFF” shows the function is deactivated.
Does the system setting comply with
the customer’s contract?

NOTE:
Setting of “VEHICLE TRACKING” must
be ON at any time.

OK

E

NG

If either setting is “OFF”,
contact the Communicator
Response Center at 1-888-
427-4812 to verify the sys-
tem setting.
NOTE:
Whenever dialing the
above number, some
information about the
vehicle is required by the
operator. For details,
refer to EL-506.

System setting is OK.

INFINITI COMMUNICATOR (IVCS)

Trouble Diagnoses (Cont’d)

H

EL-530
