TERMINALS AND REFERENCE VALUE FOR CONTROL UNIT

AV-217

[WITH MOBILE ENTERTAINMENT SYSTEM]

C

D

E

F

G

H

I

J

L

M

A

B

AV

Rear Display Unit

NKS004AR

17

(W/L)

Ground

Communication signal
(DISP-CONT)

Output

ON

When adjusting display
brightness.

18

Shield

19

(O/L)

Ground

Communication signal
(CONT-DISP)

Input

ON

When adjusting display
brightness.

20

(V)

Ground

ACC power supply

Input

ACC

Battery voltage

21

(L)

Ground

Battery power supply

Input

OFF

Battery voltage

23

(B)

Ground

Ground

ON

Approx. 0 V

Terminal

(Wire color)

Item

Signal

input/

output

Condition

Reference value

+

Ignition

switch

Operation

PKIB5039J

PKIB5039J

Terminal

(Wire color)

Item

Signal

input/

output

Condition

Reference value

+

Ignition

switch

Operation

1

(B/Y)

Ground

Ground

ON

Approx. 0 V

2

(B/Y)

Ground

Ground

ON

Approx. 0 V

3

(L/O)

Ground

Battery power supply

Input

OFF

Battery voltage

4

(L/Y)

Ground

Battery power supply

Input

OFF

Battery voltage

6

(W/L)

Ground

ACC power supply

Input

ACC

Battery voltage

8

Shield

9

(L)

Ground

Communication signal
(DISP-DIST)

Output

ON

When adjusting display
brightness.

PKIB5039J

AV-218

[WITH MOBILE ENTERTAINMENT SYSTEM]

TERMINALS AND REFERENCE VALUE FOR CONTROL UNIT

10

(B/W)

Ground

Communication signal
(DIST-DISP)

Input

ON

When adjusting display
brightness.

12

(L/W)

Ground

Ignition signal

Input

ON

Approx. 0 V

ACC

Approx. 5 V

14

Shield

15

(LG)

Ground

Image synchronizing sig-
nal

Input

ON

Rear display
DVD image

16

(V)

Ground

Composite image signal

Input

ON

Rear display
DVD image

17

(W/L)

Ground

RGB area (YS) signal

Input

ON

When inputting RGB image.

Approx. 5 V

Rear display
DVD image

18

Shield

19

(L/O)

Ground

Vertical synchronizing
(VP)  signal

Output

ON

20

(L/Y)

Ground

Horizontal synchronizing
(HP) signal

Output

ON

21

(B)

Ground

RGB ground

ON

Approx. 0 V

Terminal

(Wire color)

Item

Signal

input/

output

Condition

Reference value

+

Ignition

switch

Operation

PKIB5039J

SKIA0187E

SKIB2251J

PKIB4949J

SKIB0823E

SKIB0825E

TERMINALS AND REFERENCE VALUE FOR CONTROL UNIT

AV-219

[WITH MOBILE ENTERTAINMENT SYSTEM]

C

D

E

F

G

H

I

J

L

M

A

B

AV

DVD Player

NKS004AS

22

(G)

21

(B)

RGB signal (B: blue)

Input

ON

Start confirmation/adjust-
ment mode, and then dis-
play color bar by selecting
“Color Spectrum Bar” on
DISPLAY DIAGNOSIS
screen.

23

(R)

21

(B)

RGB signal (G: green)

Input

ON

Start confirmation/adjust-
ment mode, and then dis-
play color bar by selecting
“Color Spectrum Bar” on
DISPLAY DIAGNOSIS
screen.

24

(W)

21

(B)

RGB signal (R: red)

Input

ON

Start confirmation/adjust-
ment mode, and then dis-
play color bar by selecting
“Color Spectrum Bar” on
DISPLAY DIAGNOSIS
screen.

Terminal

(Wire color)

Item

Signal

input/

output

Condition

Reference value

+

Ignition

switch

Operation

SKIB2237J

SKIB2236J

SKIB2238J

Terminal

Item

Signal

input/

output

Condition

Reference value

+

Ignition

switch

Operation

1

(Y/R)

Ground

Battery power supply

Input

OFF

Battery voltage

2

(V)

Ground

ACC power supply

Input

ACC

Battery voltage

7

(W/L)

6

(B)

AUX sound signal RH

Input

ON

AUX sound input

8

(R/W)

Shield

14

(L/W)

Shield

15

(Y)

Communication signal
(H)

Input/

Output

16

(W)

Communication signal
(H)

Input/

Output

17

(B/P)

Ground

Ground

ON

Approx. 0 V

18

(R/L)

Ground

Illumination signal

Input

OFF

Lighting switch is OFF.

Approx. 0 V

Lighting switch is ON.

Approx. 12 V

SKIB3609E

AV-220

[WITH MOBILE ENTERTAINMENT SYSTEM]

TERMINALS AND REFERENCE VALUE FOR CONTROL UNIT

19

(G/Y)

Shield

20

(G)

Ground

DVD image signal

Output

ON

DVD image

23

(R)

22

(B)

AUX sound signal LH

Input

ON

AUX sound input

24

(L/R)

Shield

25

(W/R)

9

(B/Y)

Headphone signal LH

Output

ON

Sound output

26

(L)

10

(G/B)

Headphone signal RH

Output

ON

Sound output

27

(B/R)

11

(BR)

Sound signal LH

Output

ON

Sound output

28

(B/W)

12

(L)

Sound signal RH

Output

ON

Sound output

30

(G/R)

Shield

31

(O)

Communication signal
(L)

Input/

Output

32

(R)

Communication signal
(L)

Input/

Output

Terminal

Item

Signal

input/

output

Condition

Reference value

+

Ignition

switch

Operation

SKIB2251J

SKIB3609E

SKIB3609E

SKIB3609E

SKIB3609E

SKIB3609E
