Idle speed should be:
730
50 rpm (in Park or neutral)
Idle speed should be:
730
50 rpm (in Park or neutral)
11-272
Idle Control System
Idle Speed Inspection
A
NOTE:
• Before checking the idle speed, check these items:
– The malfunction indicator lamp (MIL) has not been
reported on, and there are no DTCs.
– Ignition timing
– Spark plugs
– Air cleaner
– PCV system
• Apply the parking brake.
1. Disconnect the evaporative emission (EVAP)
canister purge valve connector.
2. Connect the HDS to the data link connector (DLC)
(A) located under the driver’s side of the dashboard.
3. Start the engine. Hold the engine speed at
3,000 rpm without load (in Park or neutral) until the
radiator fan comes on, then let it idle.
4. Check the idle speed without load conditions:
headlights, blower fan, radiator fan, and air
conditioner off.
5. Let the engine idle for 1 minute with high electric
load (A/C switch ON, temperature set to Max Cool,
blower fan on High, and headlights on high beam).
NOTE: If the idle speed is not within specification,
do the PCM idle learn procedure (see page 11-273).
If the idle speed is still not within specification, go
to symptom troubleshooting.
6. Reconnect the EVAP canister purge valve
connector.
