Fig. 35: Identifying Seat Frame Seat Cushion Cover/Pad
Courtesy of AMERICAN HONDA MOTOR CO., INC.

14. Pull back the edge of the seat cushion cover all the way around, and release the clips (A), then remove the

seat cushion cover.

Fig. 36: Identifying Seat Cushion Cover Clips
Courtesy of AMERICAN HONDA MOTOR CO., INC.

15. Install the cover in the reverse order of removal, and note these items:



To prevent wrinkles when installing a seat cushion cover, make sure the material is stretched
evenly over the pad before securing the clips and hooks.



Replace any clips you removed with new ones (A). Install them with commercially available
upholstery ring pliers (B).



2007 Honda Element EX

2007-08 ACCESSORIES AND EQUIPMENT Seats - Element



Fig. 37: Identifying Clips And Upholstery Ring Pliers
Courtesy of AMERICAN HONDA MOTOR CO., INC.

FRONT SEAT ARMREST REPLACEMENT

FOR SOME MODELS

1. Unzip the armrest cover (A), and pull back the armrest cover.

Fig. 38: Identifying Armrest Cover With Torque Specification
Courtesy of AMERICAN HONDA MOTOR CO., INC.

2. Remove the nut, the wave washer (B), and the washer (C), then remove the armrest (D). If necessary,

remove the bushings (E) from the armrest.

3. Remove the bolts, then remove the armrest bracket (A).

NOTE:

Take care not to tear the seams or damage the seat covers.



2007 Honda Element EX

2007-08 ACCESSORIES AND EQUIPMENT Seats - Element



Fig. 39: Identifying Armrest Bracket Bolts With Torque Specification
Courtesy of AMERICAN HONDA MOTOR CO., INC.

4. Install the armrest in the reverse order of removal.

REAR SEAT DISASSEMBLY/REASSEMBLY

Special Tools Required

KTC trim tool set SOJATP2014 *

* Available through the American Honda Tool and Equipment Program; call 888-424-6857

1. Fold the seat-back rearward.

2. Pull the pivot bracket cover (A) away from the pivot bracket (B), and release the hook (C).

NOTE:



Use the appropriate tool from the KTC trim tool set to avoid damage when
prying components.



Take care not to scratch the body or tear the seat covers.



Put on gloves to protect your hands.



2007 Honda Element EX

2007-08 ACCESSORIES AND EQUIPMENT Seats - Element



Fig. 40: Removing Pivot Bracket Cover Away From Pivot Bracket
Courtesy of AMERICAN HONDA MOTOR CO., INC.

3. Fold the seat-back forward.

4. Remove the head restraint.

5. Remove the pivot bracket cover (A), and remove the E clip (B) from the center pivot (C).

Fig. 41: Identifying Pivot Bracket Cover And Center Pivot E Clip
Courtesy of AMERICAN HONDA MOTOR CO., INC.

6. Release the hook strip, and with seat-back loops, unzip the seat-back cover (see step 3 on Rear Seat-

back Cover Replacement ), then pull back the cover.

7. Pull back the seat-back pad (A), and remove the bolts.



2007 Honda Element EX

2007-08 ACCESSORIES AND EQUIPMENT Seats - Element
