Honda Element. Manual - part 729

Fig. 27: Removing Out Center Cover
Courtesy of AMERICAN HONDA MOTOR CO., INC.

4. Remove the seat belt lower anchor (A).

Fig. 28: Identifying Seat Belt Lower Anchor With Torque Specification
Courtesy of AMERICAN HONDA MOTOR CO., INC.

5. Release the clips and hook(s) (A) from the seat frame.

Driver's seat



2007 Honda Element EX

2007-08 ACCESSORIES AND EQUIPMENT Seats - Element



Fig. 29: Identifying Seat Frame For Driver's Seat Clips And Hooks
Courtesy of AMERICAN HONDA MOTOR CO., INC.

Passenger's seat

Fig. 30: Identifying Seat Frame For Passenger's Seat Clips And Hooks
Courtesy of AMERICAN HONDA MOTOR CO., INC.

6. Remove the center anchor bolt (A), then remove the seat belt buckle (B).

Driver's Seat



2007 Honda Element EX

2007-08 ACCESSORIES AND EQUIPMENT Seats - Element



Fig. 31: Identifying Center Anchor Bolt With Torque Specification (Driver's Seat)
Courtesy of AMERICAN HONDA MOTOR CO., INC.

Passenger's seat

Fig. 32: Identifying Center Anchor Bolt With Torque Specification (Passenger's Seat)
Courtesy of AMERICAN HONDA MOTOR CO., INC.

7. Driver's seat: Release the clips.

8. Release the hooks (C) from the seat frame.

9. Release the hook springs (A), pull the seat cushion cover (B).

Driver's seat



2007 Honda Element EX

2007-08 ACCESSORIES AND EQUIPMENT Seats - Element



Fig. 33: Identifying Hook Springs And Seat Cushion Cover (Driver's Seat)
Courtesy of AMERICAN HONDA MOTOR CO., INC.

Passenger's seat

Fig. 34: Identifying Hook Springs And Seat Cushion Cover (Passenger's Seat)
Courtesy of AMERICAN HONDA MOTOR CO., INC.

10. From under the seat cushion, release the hooks (C) from the seat cushion frame spring (D).

11. Release the hooks (E) from the seat cushion frame.

12. Passenger's seat: Release the clip (F).

13. Remove the seat cushion cover/pad (A) from the seat frame (B).



2007 Honda Element EX

2007-08 ACCESSORIES AND EQUIPMENT Seats - Element
