Fig. 21: Identifying Shoulder Front Seat Cover Screws
Courtesy of AMERICAN HONDA MOTOR CO., INC.

14. Remove the seat-back cover/pad (A) from the seat-back frame (B).

Fig. 22: Identifying Seat-Back Frame Seat-Back Cover/Pad
Courtesy of AMERICAN HONDA MOTOR CO., INC.

15. Pull back the edge of the seat-back cover all the way around, and release the clips (A), then remove the

seat-back cover.



2007 Honda Element EX

2007-08 ACCESSORIES AND EQUIPMENT Seats - Element



Fig. 23: Identifying Seat-Back Cover
Courtesy of AMERICAN HONDA MOTOR CO., INC.

16. Install the cover in the reverse order of removal, and note these items:



Reinitialize the ODS unit (see ODS UNIT INITIALIZATION ).



To prevent wrinkles when installing a seat-back cover, make sure the material is stretched evenly
over the pad before securing the clips, hooks, and hook strips.



Replace any clips you removed with new ones (A). Install them with commercially available
upholstery ring pliers (B).



Make sure the side airbag harness and ODS subharness (passenger's seat) are routed properly.

Fig. 24: Identifying Upholstery Ring Pliers And Clips
Courtesy of AMERICAN HONDA MOTOR CO., INC.

FRONT SEAT CUSHION COVER REPLACEMENT

Special Tools Required



2007 Honda Element EX

2007-08 ACCESSORIES AND EQUIPMENT Seats - Element



KTC trim tool set SOJATP2014 *

* Available through the American Honda Tool and Equipment Program; call 888-424-6857

SRS components are located in this area. Review the SRS component locations (see COMPONENT
LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES )
before doing repairs or service.



Check the operation of the driver's seat position sensor after any of these actions (see DRIVER'S SEAT
POSITION SENSOR OPERATION CHECK ).



Driver's seat position sensor replacement



Cover plate (front side of driver's seat slide rail) replacement



Calibrate the ODS unit after any of these actions (see ODS UNIT CALIBRATION ).



Front passenger's seat replacement (including any seat components)



Replacement of the seat weight sensors



After a vehicle collision

1. Remove the front seat (see FRONT SEAT REMOVAL/INSTALLATION ).

2. Remove the recline cover (A).

-1 Remove the recline knob (B).

-2 Driver's seat: Pull back the cap (C) to release the hooks (D), and remove the snap ring (E), then
remove the height handle (F).

-3 Gently pull out the cover to detach the clip, and release the hooks (G).

Driver's seat

NOTE:



Use the appropriate tool from the KTC trim tool set to avoid damage when
prying components.



Take care not to tear the seams or damage the seat covers.



Put on gloves to protect your hands.



2007 Honda Element EX

2007-08 ACCESSORIES AND EQUIPMENT Seats - Element



Fig. 25: Identifying Recline Cover (Driver's Seat)
Courtesy of AMERICAN HONDA MOTOR CO., INC.

Passenger's seat

Fig. 26: Identifying Recline Cover (Passenger's Seat)
Courtesy of AMERICAN HONDA MOTOR CO., INC.

3. Gently pull out the center cover (A) to detach the clip, and release the hooks (B).
