3. Install the left side oil seal (A) even and flush with the machined edge of the rear differential carrier

assembly using the oil seal driver (B). Be careful not to damage the lip of the oil seal.

Fig. 28: Identifying Left Side Oil Seal
Courtesy of AMERICAN HONDA MOTOR CO., INC.

4. Remove the companion flange (see step 2 on Rear Differential Disassembly ).

5. Remove the oil seal (A) from the torque control differential (TCD) case (B).

Fig. 29: Identifying Oil Seal
Courtesy of AMERICAN HONDA MOTOR CO., INC.

6. Install the oil seal (A) even and flush with the case using the oil seal driver (B). Be careful not to damage

the lip of the oil seal.

NOTE:

Be careful not to damage the shaft or case while prying out the oil seal.



2007 Honda Element EX

2007-08 DRIVELINE/AXLES Rear Differential - Element



Fig. 30: Identifying Oil Seal
Courtesy of AMERICAN HONDA MOTOR CO., INC.

7. Install the companion flange (see step 9 on Rear Differential Reassembly ).

REAR DIFFERENTIAL DISASSEMBLY

Special Tools Required



Holder handle 07JAB-001020A



Companion flange holder 07RAB-TB4010B

1. Remove the drain plug (A), the filler plug (B), and washers (C).

Fig. 31: Identifying Drain Plug, Filler Plug And Washers
Courtesy of AMERICAN HONDA MOTOR CO., INC.

2. Lift up the locking tab on the lock nut (A) from the groove of the clutch guide, making sure that the tab

completely clears the groove to prevent damaging the clutch guide.



2007 Honda Element EX

2007-08 DRIVELINE/AXLES Rear Differential - Element



Fig. 32: Lifting Locking Tab On Lock Nut
Courtesy of AMERICAN HONDA MOTOR CO., INC.

3. Install the companion flange holder (A) and holder handle (B) on the companion flange.

Fig. 33: Identifying Companion Flange Holder And Holder Handle With Torque Specification
Courtesy of AMERICAN HONDA MOTOR CO., INC.

4. Loosen the locknut (A) counterclockwise so that its tab (B) comes out from the groove (C) in the clutch

guide.



2007 Honda Element EX

2007-08 DRIVELINE/AXLES Rear Differential - Element



Fig. 34: Identifying Locknut
Courtesy of AMERICAN HONDA MOTOR CO., INC.

5. Tighten the locknut (A) until its tab (B) aligns with the groove (C).

Fig. 35: Identifying Locknut, Tab And Groove
Courtesy of AMERICAN HONDA MOTOR CO., INC.

6. Clean any dirt from inside of the groove in the clutch guide.

7. Remove the locknut (A), the spring washer (B), the back-up ring (C), the O-ring (D), and the companion

flange (E).
