Fig. 65: Identifying Clutch Cover Bolts With Torque Specification
Courtesy of AMERICAN HONDA MOTOR CO., INC.
7. If the engine is still in the vehicle, install the subframe.
-1 Support the subframe with the subframe adapter and a jack, and lift it up to the body, then
loosely install the new subframe mounting bolts (see step 12 in ENGINE INSTALLATION ).
-2 Align the reference marks with the center of the subframe mounting bolts, then torque the bolts
to the specified torque (see step 14 in ENGINE INSTALLATION ).
-3 A/T model: Install the automatic transmission fluid (ATF) filter mounting bolt (see step 36 in
ENGINE INSTALLATION ).
-4 Torque the rear mount mounting bolts (see step 16 in ENGINE INSTALLATION ).
-5 Torque the front mount mounting bolt (see step 15 in ENGINE INSTALLATION ).
-6 Connect the suspension knuckle ball joints (see LOWER ARM REPLACEMENT ).
8. After assembly, wait at least 30 minutes before filling the engine with oil.
TRANSMISSION END CRANKSHAFT OIL SEAL INSTALLATION - IN CAR
Special Tools Required
Handle Driver 07749-0010000
Oil seal driver attachment 96 07ZAD-PNAA100
1. Clean and dry the crankshaft oil seal housing.
2. Apply a light coat of multipurpose grease to the crankshaft and to the lip of the seal.
3. Use the handle driver and oil seal driver attachment to drive a new oil seal squarely into the engine block
to the specified installed height.
2007 Honda Element EX
2007-08 ENGINE Engine Block - Element
