Fig. 13: Identifying Front Lock And Rear Lock Cable
Courtesy of AMERICAN HONDA MOTOR CO., INC.

5. Install the locks in the reverse order of removal, and make sure they are connected securely.

CENTER CONSOLE DISASSEMBLY/REASSEMBLY

Special Tools Required

KTC trim tool set SOJATP2014 *

* Available through the American Honda Tool and Equipment Program; call 888-424-6857

SC MODEL

1. Remove the these items:



Center console (see CENTER CONSOLE REMOVAL/INSTALLATION )



Center console armrest (see CENTER CONSOLE ARMREST REMOVAL/INSTALLATION )

2. Gently pull out the driver's console trim (A) to detach the clips (B, C), then remove the trim by releasing

the hooks (D).

NOTE:



Put on gloves to protect your hands.



Use the appropriate tool from the KTC trim tool set to avoid damage when
prying components.



Take care not to scratch the center console and related parts.



2007 Honda Element EX

2007-08 ACCESSORIES AND EQUIPMENT Consoles - Element



Fig. 14: Identifying Trim By Releasing Hooks
Courtesy of AMERICAN HONDA MOTOR CO., INC.

3. Remove the screws, then remove the driver's center console side trim (A) from the center console (B).

Fig. 15: Identifying Center Console Trim And Screws
Courtesy of AMERICAN HONDA MOTOR CO., INC.

4. Remove the screws (A, B), and pull out the passenger's console trim (C) to detach the clips (D), then

remove it.



2007 Honda Element EX

2007-08 ACCESSORIES AND EQUIPMENT Consoles - Element



Fig. 16: Identifying Passenger's Console Trim Clips And Screws
Courtesy of AMERICAN HONDA MOTOR CO., INC.

5. Remove the screws, then remove the center passenger's console side trim (A) from the center console (B).

Fig. 17: Identifying Center Passenger's Console Trim Screws
Courtesy of AMERICAN HONDA MOTOR CO., INC.

6. Remove the center console (A).

-1 Disconnect the console accessory power socket connector (B) and auxiliary jack connector (C),
and detach the harness clips (D), then remove the console wire harness (E).

-2 Remove the screw (F), and remove the harness bracket (G).

-3 Pull out the maintenance lid (H) to detach the clip (I), and remove it.

-4 Remove the screws (J), then pull out the center console (K) to detach the clips (L), and remove



2007 Honda Element EX

2007-08 ACCESSORIES AND EQUIPMENT Consoles - Element



it.

Fig. 18: Identifying Center Console
Courtesy of AMERICAN HONDA MOTOR CO., INC.

7. Remove the screws, and remove the lower hinge bracket (A) and lower hinge (B) from the console box

(C).

Fig. 19: Identifying Console Box Lower Hinge Bracket And Screws
