Honda Accord Electrical Troubleshooting Manual - part 91

120. Behind Glove Box

C201
(16-BLU)

C203
(5-GRY)

C202
(7-BRN)

122. Behind Right Kick Panel (V6) (’98-’00 Models)

ABS CONTROL
UNIT CONNECTOR
A (22-ORN)

ABS CONTROL
UNIT CONNECTOR
B (12-ORN)

123. Behind Right Kick Panel

G205
(V6 ONLY)

TAILLIGHT RELAY (EX)
HIGH BEAM CUT RELAY
(Canada)
PRIMARY HO2S RELAY
(’98-’00 Models) (ULEV)
A/F SENSOR HEATED
CONTROL RELAY
(’01-’02 Models) (ULEV)

G204
(V6 ONLY)

124. Below Driver’s Seat, Carpet Pulled Back

DRIVER’S SIDE
IMPACT SENSOR
(’00-’02 Models)

G551
